Fleetguard AF26562 00JX Safety Filter Cartridges

AF26562 00JX safety filter cartridges provide dual protection for engine air intake systems, serving as a complementary safety filter for standard Fleetguard air filters. They are mainly used to capture fine particles not fully filtered by the primary filter, preventing dust and contaminants from entering cylinders and causing abrasion.

Featuring high-precision composite filter media, stable pleated structure, and reliable sealing design, the cartridges ensure zero bypass and leakage. Suitable for engineering machinery, generator sets, commercial vehicles and other heavy‑duty applications, they perform reliably in dusty conditions.

Compliant with original specifications for precise fit and easy installation, they work with the primary filter to improve air cleanliness, extend engine service life and reduce maintenance risks.

Advantages of  AF26562 00JX Safety Filter Cartridges

  • Dual Protection & Enhanced Reliability: Acts as a final safety barrier, working with the primary filter to minimize particle penetration and protect key engine components.

  • High-Precision Filtration: Uses dense, high-efficiency filter media for excellent fine-particle capture, delivering cleaner intake air and reducing cylinder wear.

  • Stable & Durable Structure: Optimized pleating and sealing resist pulse pressure and deformation, ensuring no breakage or air leakage for consistent performance.

  • Original-Equivalent Compatibility: Precise dimensions for easy installation, perfect match with mainstream models, no modification or abnormal noise, simplifying maintenance.

Technical Specifications

Part Number:
AF26562 00JX
Filter Type: Air Safety Filter (Secondary/Inner Filter)
Dimensions: OD 133 mm × ID 95 mm × Height 306 mm
Connection Specs Radial Seal, Non-threaded
Filtration Precision: ≥5 μm
Filtration Efficiency: ≥99.5%
Applicable Models/Platforms: Cummins series, Matching with AF26561 Primary Filter, Construction machinery, etc.
Operating Conditions: -30℃ ~ +100℃, Normal Pressure
Lead Time: 15 – 30 Working Days
Payment Terms: T/T ,L/C
your 360 images

Filter Model

Dimensions

Connection Specs

Filtration Precision

Filtration Efficiency

AF26562 00JX OD 133 mm × ID 95 mm × Height 306 mm Radial Seal, Non-threaded ≥5 μm ≥99.5%
AF872-B-AM OD 351mm × Height 470 mm Top Open / Bottom Closed, Axial Seal 0.5μm ≥99.95%
AF928M-B-AM OD Φ307mm, ID Φ196mm, Height 398mm Axial seal, non-threaded ≥5 μm ≥99.5%
A340005305 OD 152mm × Height 1016 mm 226 double open end 10μm ≥99.5%
AF26561 00JX OD Φ202 mm, ID Φ133.4 mm, Height 502 mm Radial seal / Snap-in ≥10 μm ≥99.7%
AF26509 00JX OD 160mm × Height 280 mm PU seal, bayonet mounting 10μm ≥99.9%
——END——

General Infomation of DCEC C220-10A Automotive Engine

Engine Model C220-10A Advertised Power 220 HP @ 2400 RPM
Peak Torque 780 N.m @ 1500 RPM Curve&Datasheet FR 91484
Fuel System Bosch P7100 Pump No. Of Cylinders 6
Aspiration Turbocharged & Air Intercooler Displacement 8.3 L
Bore * Stroke 114 mm * 135 mm CPL Code Revision 8418
Dry Weight  617 kg Wet Weight  636 kg
Compression Ratio 17.3 : 1

Installation Data of DCEC C220-10A Automotive Engine

Center of Gravity. Distance From Front Face of Block 427 mm
Center of Gravity. Distance Above Crank Centerline(Above Crankshaft) 163 mm
Maximum Bending Moment At Rear Face of Block 1356 N.m
Maximum Crankshaft Thrust Bearing load limit- Intermittent load 3558 N
Maximum Crankshaft Thrust Bearing load limit-Continuous load 2670 N
Instantaneous Inertia At Rotating: (Without Flywheel)  N/A
Emissions Certification GB17691/GB14761
Idle Speed 800 RPM
Maximum Non-Load Speed 2720 RPM
Over Speed Performance (Within 15 Seconds) 3500 RPM
The Clutch Torque @ 800Rpm 495 N.m
Maximum Altitude At Which Continuous operation Is Allowed 3000 m
Supercharger outlet Exhaust Pressure limit Value  450 kPa
Maximum Power of Exhaust Brake 114 kW
——END——

Engine Performance Data Rated power of DCEC C220-10A Automotive Drive Engine

Rated Power Torque Peak Rated Power Torque Peak
Engine Speed 2400 RPM 1500 RPM Exhaust Temperature 625 ℃ 602 ℃
Oil Pressure 345 kPa 282 kPa Fuel Consumption 43 L/hr 26.9 L/hr
The Air Flow 18.9 m³/min 9.1 m³/min Coolant Flow N/A N/A
The Flow Rate of Pressurized Air N/A N/A Heat Loss Coolant 77 kW 60 kW
Pressurized Air Pressure N/A N/A Heat Loss Air 46 kW 14 kW
The Exhaust Flow 45 m³/min 21.3 m³/min Mechanical Loss of Power N/A N/A


System Technical Data of DCEC C220-10A Automotive Drive Engine

Air Intake System Maximum Temperature Rise Between Ambient Air and Engine Air Inlet 15
Maximum Intake Restriction with Dry Type Air Cleaner,with Clean Filter-Medium Duty 2.9 (300) kPa (mmH2O)
Maximum Intake Restriction with Dry Type Air Cleaner,with Clean Filter-Heavy Duty 3.7 (380) kPa (mmH2O)
Maximum Intake Restriction with Dirty Filter 6.2 (635) kPa (mmH2O)
Turbocharged & Intercooled Maximum Intake Manifold Temperature-Second Level 55
Maximum Intake Manifold Temperature-Three-Level 50
Intercooler Cooling Temperature-Second Level 25
Intercooler Cooling Temperature-Three-Level 20
Maximum Allowable Pressure Difference Before and After Intercooling-Three-Level 16.7 (125) kPa(mmHg)
Minimum Inlet Pipe Diameter Allowed-Three-Level 75 mm
Exhaust System Maximum Back Pressure Imposed by Complete Exhaust System 10.0 (75) kPa (mmHg)
Exhaust Pipe Size Normally Accepable 75 mm
Maximum Static Bend Allowed for Turbocharger Exhaust Flange N/A
Lubrication System Low oil Level Inclination Angle-Front Up 45 °
Low oil Level Inclination Angle-Back Up 45 °
Low oil Level Inclination Angle-Fuel Pump Side Up 45 °
Low oil Level Inclination Angle-Exhaust Side Up 45 °
Oil Sump Capacity-Upper Limit 14.2 L
Oil Sump Capacity-Lower Limit 12.4 L
Capacity of The Whole System 16.4 L
Cooling System Coolant Capacity – Engine only 9 L
Standard Thermostat (Modulating) Range 83 – 95
Minimum Fill Rate ( Without Low Level Alarm) 19 L/min
Minimum Coolant Expansion Space – % of System Capacity 6 %
Water Tank Capacity Without Water Expansion 6 L
Maximum Coolant Pressure (Without Pressure Cap, Thermostat Closed) 276 kPa
Maximum Degassing Time 25 mins
Maximum Coolant Flow to Accessories 41 L/min
Maximum Coolant Temperature Engine out 100
Minimum Allows Pressure of Pressure Cap 50 kPa
Minimum Recommended Coolant Temperature 70
Common Operating Temperature Range of Fans with Fan Clutch 93
Maximum Coolent Temperature For Engine Protection Control 100
The Limit Environmental Temperature at Rated Speed Second Level 45 ;Three-Level 42
The Limit Environmental Temperature at Peak Torque Second Level 40 ;Three-Level 37
24V Electrical System Maximum Allowable Resistance of Cranking Circuit 0.002
The Cold Start Current When Engine and The Clutch Separate 12 V 500 24 V 250
Cold Starting System Maximum Unaided Cold Start Temperature 120 RPM -10
Maximum Aided Cold Start Temperature 110 RPM -35
Fuel System Maximum Fuel Return Resistance 520 (mmHg)
Maximum Inlet Resistance of oil Pump with Clean Filter 150 (mmHg)
——END——

Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
