PARTMAC FS0/Oil-Water Separator
The Fleetguard FS0 series fuel-water separator is a special filtration component for fuel systems of commercial vehicles and construction machinery. It is core-equipped with Stratapore™ deep filtration media, achieving 98.7% filtration efficiency for 25-micron particles and over 95% separation efficiency for free and emulsified water in accordance with SAE J1985 standard, with a rated flow range of 3.8LPM-10LPM, building the first line of protection for the fuel system.
The series is equipped with a 200W PTC constant temperature heater for low-temperature working environments, a high-transparency water collection cup for real-time observation of water accumulation, and a hand pump integrated in the base for oil circuit air exhaust. It can also be optionally equipped with four types of sensor plugs (A, B, C, D) to meet the installation adaptation requirements of different models.
The FS0 series adopts a spin-on structure with convenient disassembly and assembly and excellent sealing performance. It is recommended to replace it every 16000-20000km for commercial vehicles and 400-500 hours for construction machinery. It effectively intercepts fuel impurities and water, protects precision components such as fuel injectors, and extends the service life of the engine.
General Specifications of FS0 Series
| Series: | FS0 Series |
| Filter Type: | Fuel-Water Separator |
| Dimensions: | OD≈90-95mm, Total Height≈240-250mmmm |
| Thread Specification: | Oil Port M14/M16/M18 |
| Filtration Precision: | 20-25μm |
| Filtration Efficiency: | ≥98.7% (ISO 4548 Standard) |
| Applicable Models/Platforms: | Heavy-Duty Commercial/Construction Machinery |
| Operating Conditions: | Suitable for Low-Temp (with PTC Heater) |
| 10μm | ||||||||
| 20-25μm | ||||||||
| 20-25μm | ||||||||
| 20-25μm | ||||||||
| 20-25μm | ||||||||
| 10μm | ||||||||
| 10μm | ||||||||
| 5μm | ||||||||
Filtration Precision /μm | 0 | 5 | 10 | 15 | 20 | 25 | 30 | 35 |
Part Name | Filtration Precision | Filtration Efficiency | Part Name | Filtration Precision | Filtration Efficiency | ||
| FS01006 00MX | 10μm | ≥98% (ISO 4548 Standard) | FS01003 00MX | 20-25μm | ≥95% (ISO 4548 Standard) | ||
| FS01235 00MX | 20-25μm | ≥95% (ISO 4548 Standard) | FS01000 00MX | 10μm | ≥95% (ISO 4548 Standard) | ||
| FS01280 00MX | 20-25μm | ≥95% (ISO 4548 Standard) | FS01040 00MX | 10μm | ≥95% (ISO 4548 Standard) | ||
| FS01251 00MX | 20-25μm | ≥95% (ISO 4548 Standard) | FS01212 00MX | 5μm | ≥98% (ISO 4548 Standard) | ||
| ——END—— | |||||||
PARTMAC FS0 Series Oil-Water Separator
This is the list of all series of PARTMAC FS0 Series Oil-Water Separator
Click here to findOil-Water Separator by type
Fleetguard FS01006 00MX Oil-Water Separator
Fleetguard Filters | FS01006 00MX Oil-Water Separator
Series: FS0 Series
Part Name: Oil-Water Separator
Part Number: FS01006 00MX
Applicable Platforms:Universal for Construction Machinery / Commercial Vehicle / Diesel Engine
Fleetguard FS01212 00MX Oil-Water Separator
Fleetguard Filters | FS01212 00MX Oil-Water Separator
Series: FS0 Series
Part Name:Oil-Water Separator
Part Number: FS01212 00MX
Applicable Platforms:Universal for Construction Machinery / Commercial Vehicle / Diesel Engine
Fleetguard FS01040 00MX Oil-Water Separator
Fleetguard Filters | FS01040 00MX Oil-Water Separator
Series: FS0 Series
Part Name: Oil-Water Separator
Part Number: FS01040 00MX
Applicable Platforms:Universal for Construction Machinery / Commercial Vehicle / Diesel Engine
Fleetguard FS01000 00MX Oil-Water Separator
Fleetguard Filters | FS01000 00MX Oil-Water Separator
Series: FS0 Series
Part Name:Oil-Water Separator
Part Number: FS01000 00MX
Applicable Platforms:Universal for Construction Machinery / Commercial Vehicle / Diesel Engine
Fleetguard FS01003 00MX Oil-Water Separator
Fleetguard Filters | FS01003 00MX Oil-Water Separator
Series: FS0 Series
Part Name: Oil-Water Separator
Part Number: FS01003 00MX
Applicable Platforms:Heavy-Duty Commercial Vehicles/Construction Machinery
Fleetguard FS01251 00MX Oil-Water Separator
Fleetguard Filters | FS01251 00MXOil-Water Separator
Series: FS0 Series
Part Name: Oil-Water Separator
Part Number: FS01251 00MX
Applicable Platforms:Heavy-Duty Commercial Vehicles/Construction Machinery
Fleetguard FS01280 00MX Oil-Water Separator
Fleetguard Filters | FS01280 00MX Oil-Water Separator
Series: FS0 Series
Part Name: Oil-Water Separator
Part Number: FS01280 00MX
Applicable Platforms:Heavy-Duty Commercial Vehicles/Construction Machinery
Fleetguard FS01235 00MX Oil-Water Separator
Fleetguard Filters | FS01235 00MX Oil-Water Separator
Series: FS0 Series
Part Name: Oil-Water SeparatorSeparator
Part Number: FS01235 00MX
Applicable Platforms:Heavy-Duty Commercial Vehicles/Construction Machinery
