Fleetguard FS01280 00MX Oil-Water Separator

The FS01280 00MX Oil-Water Separator is a core filtration component of the FS0 series, specially designed for heavy-duty commercial vehicle and engineering machinery diesel fuel systems. It adopts professional deep filtration media and efficient coalescing separation technology, which can accurately separate fuel and water and intercept solid impurities, effectively improving fuel purity and providing reliable protection for high-pressure oil pumps, fuel injectors and other precision components. It is a perfect OEM matching part for mainstream heavy-duty engine platforms.

With an optimized spin-on structural design, the product has a compact layout and fits the standard installation space of heavy-duty equipment fuel systems. Its outer diameter ranges from 90-95mm and total height from 240-250mm, with excellent structural stability. Equipped with a high-sealing integral gasket, it can avoid fuel leakage and air intake, and adapt to the long-term vibration working condition of heavy-duty equipment.

This product has passed strict performance testing, with stable and durable working performance. It can maintain high-efficiency filtration and water separation effects in the conventional working temperature range of diesel engines, effectively reduce the failure rate of fuel system components, extend the maintenance cycle of the whole machine, and reduce the operation and maintenance cost of equipment for users.

Advantages of  FS01280 00MX Oil-Water Separator

  • High-efficiency Filtration & Separation: Adopts advanced Stratapore™ deep filtration media, with 20-25μm filtration precision and over 98.7% particle filtration efficiency, and water separation efficiency up to 95% or more, thoroughly removing water and impurities in fuel to protect precision components.

  • Excellent Structural Stability: Optimized spin-on structure with thickened shell material, strong anti-vibration and impact resistance, suitable for the harsh working environment of heavy-duty commercial vehicles and engineering machinery, without easy damage.

  • Reliable Sealing Performance: Equipped with high-quality integral rubber gasket, with good oil resistance and aging resistance, ensuring tight sealing of the fuel circuit, effectively preventing fuel leakage and air intake, and ensuring stable fuel supply.

  • Easy Installation & Maintenance: Matches standard M14/M16/M18 oil port specifications, no professional tools required for disassembly and assembly, realizing quick replacement of the filter, shortening maintenance time and reducing equipment downtime loss.

Technical Specifications

Part Number:FS01280 00MX
Filter Type:Oil-Water Separator
Dimensions:Outer Diameter≈90-95mm, Overall Height≈240-250mm
Connection Specs:Thread Specification:Oil Port M14/M16/M18
Filtration Precision:20-25μm
Filtration Efficiency:≥95% (ISO 4548 Standard)
Applicable Models/Platforms:Heavy-Duty Commercial Vehicles, Construction Machinery
Operating Conditions:Conventional Temp, Vibration & Impact Resistant
Lead Time:15 – 30 Working Days
Payment Terms:T/T ,L/C

Coming soon

Filter Model

Dimensions

Connection Specs

Filtration Precision

Filtration Efficiency

FS01280 00MXOuter Diameter≈90-95mm, Overall Height≈240-250mmThread Specification:Oil Port M14/M16/M1820-25μm≥95% (ISO 4548 Standard)
FS01235 00MXOuter Diameter≈70-80mm, Overall Height≈100-120mmThread Specification: M16×1.520-25μm≥95% (ISO 4548 Standard)
FS01251 00MXOuter Diameter≈90-95mm, Overall Height≈240-250mmThread Specification: M14/M16/M1820-25μm≥95% (ISO 4548 Standard)
FS01003 00MXOuter Diameter≈90-95mm, Overall Height≈240-250mmThread Specification: M14/M16/M1820-25μm≥95%(ISO 4548 Standard)
FS01000 00MXOuter Diameter≈Φ90~110mm, Overall Height≈170~200mmThread Specification: 1/2″ NPT Female Thread10μm≥95% (ISO 4548 Standard)
FS01040 00MXOuter Diameter≈Φ90~110mm, Overall Height≈170~200mmThread Specification: 1/2″ NPT Female Thread10μm≥95% (ISO 4548 Standard)
FS01212 00MXOuter Diameter≈Φ90~110mm, Overall Height≈170~200mmThread Specification: 1/2″ NPT Female Thread5μm≥98% (ISO 4548 Standard)
FS01006 00MXOuter Diameter≈116.2~116.5mm, Overall Height≈ 313.0~314.2mmThread Specification: 1 1/4-12UNS-2B10μm≥98%(ISO 4548 Standard)
——END——

General Infomation of DCEC C220-10A Automotive Engine

Engine ModelC220-10AAdvertised Power220 HP @ 2400 RPM
Peak Torque780 N.m @ 1500 RPMCurve&DatasheetFR 91484
Fuel SystemBosch P7100 PumpNo. Of Cylinders6
AspirationTurbocharged & Air IntercoolerDisplacement8.3 L
Bore * Stroke114 mm * 135 mmCPL Code Revision8418
Dry Weight 617 kgWet Weight 636 kg
Compression Ratio17.3 : 1

Installation Data of DCEC C220-10A Automotive Engine

Center of Gravity. Distance From Front Face of Block427 mm
Center of Gravity. Distance Above Crank Centerline(Above Crankshaft)163 mm
Maximum Bending Moment At Rear Face of Block1356 N.m
Maximum Crankshaft Thrust Bearing load limit- Intermittent load3558 N
Maximum Crankshaft Thrust Bearing load limit-Continuous load2670 N
Instantaneous Inertia At Rotating: (Without Flywheel) N/A
Emissions CertificationGB17691/GB14761
Idle Speed800 RPM
Maximum Non-Load Speed2720 RPM
Over Speed Performance (Within 15 Seconds)3500 RPM
The Clutch Torque @ 800Rpm495 N.m
Maximum Altitude At Which Continuous operation Is Allowed3000 m
Supercharger outlet Exhaust Pressure limit Value 450 kPa
Maximum Power of Exhaust Brake114 kW
——END——

Engine Performance Data Rated power of DCEC C220-10A Automotive Drive Engine

Rated PowerTorque PeakRated PowerTorque Peak
Engine Speed2400 RPM1500 RPMExhaust Temperature625 ℃602 ℃
Oil Pressure345 kPa282 kPaFuel Consumption43 L/hr26.9 L/hr
The Air Flow18.9 m³/min9.1 m³/minCoolant FlowN/AN/A
The Flow Rate of Pressurized AirN/AN/AHeat Loss Coolant77 kW60 kW
Pressurized Air PressureN/AN/AHeat Loss Air46 kW14 kW
The Exhaust Flow45 m³/min21.3 m³/minMechanical Loss of PowerN/AN/A


System Technical Data of DCEC C220-10A Automotive Drive Engine

Air Intake SystemMaximum Temperature Rise Between Ambient Air and Engine Air Inlet15
Maximum Intake Restriction with Dry Type Air Cleaner,with Clean Filter-Medium Duty2.9 (300) kPa (mmH2O)
Maximum Intake Restriction with Dry Type Air Cleaner,with Clean Filter-Heavy Duty3.7 (380) kPa (mmH2O)
Maximum Intake Restriction with Dirty Filter6.2 (635) kPa (mmH2O)
Turbocharged & IntercooledMaximum Intake Manifold Temperature-Second Level55
Maximum Intake Manifold Temperature-Three-Level50
Intercooler Cooling Temperature-Second Level25
Intercooler Cooling Temperature-Three-Level20
Maximum Allowable Pressure Difference Before and After Intercooling-Three-Level16.7 (125) kPa(mmHg)
Minimum Inlet Pipe Diameter Allowed-Three-Level75 mm
Exhaust SystemMaximum Back Pressure Imposed by Complete Exhaust System10.0 (75) kPa (mmHg)
Exhaust Pipe Size Normally Accepable75 mm
Maximum Static Bend Allowed for Turbocharger Exhaust FlangeN/A
Lubrication SystemLow oil Level Inclination Angle-Front Up45 °
Low oil Level Inclination Angle-Back Up45 °
Low oil Level Inclination Angle-Fuel Pump Side Up45 °
Low oil Level Inclination Angle-Exhaust Side Up45 °
Oil Sump Capacity-Upper Limit14.2 L
Oil Sump Capacity-Lower Limit12.4 L
Capacity of The Whole System16.4 L
Cooling SystemCoolant Capacity – Engine only9 L
Standard Thermostat (Modulating) Range83 – 95
Minimum Fill Rate ( Without Low Level Alarm)19 L/min
Minimum Coolant Expansion Space – % of System Capacity6 %
Water Tank Capacity Without Water Expansion6 L
Maximum Coolant Pressure (Without Pressure Cap, Thermostat Closed)276 kPa
Maximum Degassing Time25 mins
Maximum Coolant Flow to Accessories41 L/min
Maximum Coolant Temperature Engine out100
Minimum Allows Pressure of Pressure Cap50 kPa
Minimum Recommended Coolant Temperature70
Common Operating Temperature Range of Fans with Fan Clutch93
Maximum Coolent Temperature For Engine Protection Control100
The Limit Environmental Temperature at Rated SpeedSecond Level 45 ;Three-Level 42
The Limit Environmental Temperature at Peak TorqueSecond Level 40 ;Three-Level 37
24V Electrical SystemMaximum Allowable Resistance of Cranking Circuit0.002
The Cold Start Current When Engine and The Clutch Separate12 V 500 24 V 250
Cold Starting SystemMaximum Unaided Cold Start Temperature120 RPM -10
Maximum Aided Cold Start Temperature110 RPM -35
Fuel SystemMaximum Fuel Return Resistance520 (mmHg)
Maximum Inlet Resistance of oil Pump with Clean Filter150 (mmHg)
——END——

Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
