Fleetguard FS204458PMX Coarse Filter Cartridges

FS204458PMX coarse filter cartridges are specially designed for industrial fluid pre‑treatment applications. Adopting high‑performance composite filter media and deep‑pleated structure, they feature stable coarse particle interception capacity, efficiently removing sediment, rust, large particles and other contaminants from liquids, and significantly reducing the risk of clogging for downstream precision filter elements.

The product is compatible with standard filter housings and features strong installation versatility, acid and alkali resistance, and anti‑aging properties, ensuring stable operation in petroleum, chemical, water treatment, mechanical lubrication and other working conditions.

The overall design balances high flow rate and low pressure drop, effectively improving system filtration efficiency and extending the service life of downstream equipment and filters, making it a reliable front‑line protection component for industrial pre‑treatment.

Advantages of  FS204458PMX Coarse Filter Cartridges

  • High‑efficiency interception: Precisely captures large‑particle impurities with stable filtration efficiency, protecting downstream precision components.

  • Low pressure drop & high flow: Pleated structure increases filtration area with low flow resistance, suitable for high‑flow applications.

  • Long service life & durability: High dirt‑holding capacity and strong chemical compatibility, reducing replacement frequency and operation costs.

  • Easy installation: Standard size fits mainstream housings, simple assembly and disassembly, with excellent universality and compatibility.

Technical Specifications

Part Number:
FS204458PMX
Filter Type: Coarse Filter Cartridges
Dimensions: OD≈φ108mm,Total Height≈318mm
Connection Specs Thread Size: 1-14UNS-2B
Filtration Precision: 30μm
Filtration Efficiency: ≥99%
Applicable Models/Platforms: Cummins series, Fudai, etc.
Operating Conditions: Working pressure ≤ 0.6 MPa; Operating temperature ≤60℃;
Lead Time: 15 – 30 Working Days
Payment Terms: T/T ,L/C
your 360 images

Filter Model

Dimensions

Connection Specs

Filtration Precision

Filtration Efficiency

FS204458PMX OD≈φ108mm,Total Height≈318mm Thread Specification: 1-14UNS-2B 30μm ≥99%
FS204448PMX OD≈φ108mm,Total Height≈299mm Thread Specification: 1-14UNS-2B 30μm ≥98.5%
FS204798PMX OD≈φ110mm,Total Height≈195mm Thread Specification: 1-14UNS-2B 50μm ≥99%
FS204788PMX OD≈φ110mm,Total Height≈238mm Thread Specification: 1-14UNS-2B 50μm ≥99%
FS204048PMX OD≈φ129*21mm,Total Height≈119mm 222/226 standard end 30μm ≥99%
FS204968PMX OD≈φ114.5mm,Total Height≈175mm Thread Specification: 1-14UNS-2B 20μm ≥98%
FS204808PMX OD≈φ138.5mm,Total Height≈176mm Thread Specification: M36×1.5-6H 20μm ≥95%
FS204438PMX OD≈φ136mm,Total Height≈351mm Thread Specification: 11/2-12UNF-2B 30μm ≥98.5%
FS204008PMX OD≈φ129*21mm,Total Height≈243mm Thread Specification: 1-14UNS-2B 10μm ≥98%
FS204468PMX OD≈φ113*22mm,Total Height≈145mm 226 connection 20μm ≥95%
FS204478PMX OD≈φ112*16.8mm,Total Height≈247mm Thread Specification: 1-14UNS-2B 50μm ≥99.5%
FS204728PMX OD≈φ133mm,Total Height≈252mm Thread Specification: 1″-14UNS 25μm ≥95%
FS204708PMX OD≈φ133mm,Total Height≈248mm Thread Specification: 1-14UNS-2B 50μm ≥99%
FS203598PMX OD≈φ129mm,Total Height≈244mm Thread Specification: M16×1.5 10μm ≥98%
FS203468PMX OD≈φ111mm,Total Height≈293mm Thread Specification: 1-14UNS-2B 30μm ≥99%
FS203848PMX OD≈φ111mm,Total Height≈211mm Thread Specification: 1-14UNS-2B 10μm ≥99.5%
FS203488PMX OD≈φ111mm,Total Height≈257mm Thread Specification: M32X1.5-6H 20μm ≥99.5%
FS203408PMX OD≈φ124mm,Total Height≈262mm Thread Specification: M16×1.5 30μm ≥99.5%
FS203398PMX OD≈φ94mm,Total Height≈169mm Thread Specification: 1-14UNS 10μm ≥98%
FS203838PMX OD≈φ111.5mm,Total Height≈231mm Thread Specification: 1-14UNS-2B 25μm ≥99%
FS203478PMX OD≈φ111mm,Total Height≈319mm Thread Specification: 1-14UNS-2B 30μm ≥98%
FS203298PMX OD≈φ137mm,Total Height≈334mm Thread Specification: 1-3/8-16UNS-2B 10μm ≥98%
FS201578PMX OD≈φ111mm,Total Height≈268mm Thread Specification: 1-14UNS-2B 25μm ≥98.5%
FS201978PMX OD≈φ111.5mm,Total Height≈239mm Thread Specification: 1-14UNS-2B 25μm ≥99.5%
FS201808PMX OD≈φ108mm,Total Height≈231mm Thread Specification: 1-14UNS-2B 20μm ≥95%
——END——

General Infomation of DCEC C220-10A Automotive Engine

Engine Model C220-10A Advertised Power 220 HP @ 2400 RPM
Peak Torque 780 N.m @ 1500 RPM Curve&Datasheet FR 91484
Fuel System Bosch P7100 Pump No. Of Cylinders 6
Aspiration Turbocharged & Air Intercooler Displacement 8.3 L
Bore * Stroke 114 mm * 135 mm CPL Code Revision 8418
Dry Weight  617 kg Wet Weight  636 kg
Compression Ratio 17.3 : 1

Installation Data of DCEC C220-10A Automotive Engine

Center of Gravity. Distance From Front Face of Block 427 mm
Center of Gravity. Distance Above Crank Centerline(Above Crankshaft) 163 mm
Maximum Bending Moment At Rear Face of Block 1356 N.m
Maximum Crankshaft Thrust Bearing load limit- Intermittent load 3558 N
Maximum Crankshaft Thrust Bearing load limit-Continuous load 2670 N
Instantaneous Inertia At Rotating: (Without Flywheel)  N/A
Emissions Certification GB17691/GB14761
Idle Speed 800 RPM
Maximum Non-Load Speed 2720 RPM
Over Speed Performance (Within 15 Seconds) 3500 RPM
The Clutch Torque @ 800Rpm 495 N.m
Maximum Altitude At Which Continuous operation Is Allowed 3000 m
Supercharger outlet Exhaust Pressure limit Value  450 kPa
Maximum Power of Exhaust Brake 114 kW
——END——

Engine Performance Data Rated power of DCEC C220-10A Automotive Drive Engine

Rated Power Torque Peak Rated Power Torque Peak
Engine Speed 2400 RPM 1500 RPM Exhaust Temperature 625 ℃ 602 ℃
Oil Pressure 345 kPa 282 kPa Fuel Consumption 43 L/hr 26.9 L/hr
The Air Flow 18.9 m³/min 9.1 m³/min Coolant Flow N/A N/A
The Flow Rate of Pressurized Air N/A N/A Heat Loss Coolant 77 kW 60 kW
Pressurized Air Pressure N/A N/A Heat Loss Air 46 kW 14 kW
The Exhaust Flow 45 m³/min 21.3 m³/min Mechanical Loss of Power N/A N/A


System Technical Data of DCEC C220-10A Automotive Drive Engine

Air Intake System Maximum Temperature Rise Between Ambient Air and Engine Air Inlet 15
Maximum Intake Restriction with Dry Type Air Cleaner,with Clean Filter-Medium Duty 2.9 (300) kPa (mmH2O)
Maximum Intake Restriction with Dry Type Air Cleaner,with Clean Filter-Heavy Duty 3.7 (380) kPa (mmH2O)
Maximum Intake Restriction with Dirty Filter 6.2 (635) kPa (mmH2O)
Turbocharged & Intercooled Maximum Intake Manifold Temperature-Second Level 55
Maximum Intake Manifold Temperature-Three-Level 50
Intercooler Cooling Temperature-Second Level 25
Intercooler Cooling Temperature-Three-Level 20
Maximum Allowable Pressure Difference Before and After Intercooling-Three-Level 16.7 (125) kPa(mmHg)
Minimum Inlet Pipe Diameter Allowed-Three-Level 75 mm
Exhaust System Maximum Back Pressure Imposed by Complete Exhaust System 10.0 (75) kPa (mmHg)
Exhaust Pipe Size Normally Accepable 75 mm
Maximum Static Bend Allowed for Turbocharger Exhaust Flange N/A
Lubrication System Low oil Level Inclination Angle-Front Up 45 °
Low oil Level Inclination Angle-Back Up 45 °
Low oil Level Inclination Angle-Fuel Pump Side Up 45 °
Low oil Level Inclination Angle-Exhaust Side Up 45 °
Oil Sump Capacity-Upper Limit 14.2 L
Oil Sump Capacity-Lower Limit 12.4 L
Capacity of The Whole System 16.4 L
Cooling System Coolant Capacity – Engine only 9 L
Standard Thermostat (Modulating) Range 83 – 95
Minimum Fill Rate ( Without Low Level Alarm) 19 L/min
Minimum Coolant Expansion Space – % of System Capacity 6 %
Water Tank Capacity Without Water Expansion 6 L
Maximum Coolant Pressure (Without Pressure Cap, Thermostat Closed) 276 kPa
Maximum Degassing Time 25 mins
Maximum Coolant Flow to Accessories 41 L/min
Maximum Coolant Temperature Engine out 100
Minimum Allows Pressure of Pressure Cap 50 kPa
Minimum Recommended Coolant Temperature 70
Common Operating Temperature Range of Fans with Fan Clutch 93
Maximum Coolent Temperature For Engine Protection Control 100
The Limit Environmental Temperature at Rated Speed Second Level 45 ;Three-Level 42
The Limit Environmental Temperature at Peak Torque Second Level 40 ;Three-Level 37
24V Electrical System Maximum Allowable Resistance of Cranking Circuit 0.002
The Cold Start Current When Engine and The Clutch Separate 12 V 500 24 V 250
Cold Starting System Maximum Unaided Cold Start Temperature 120 RPM -10
Maximum Aided Cold Start Temperature 110 RPM -35
Fuel System Maximum Fuel Return Resistance 520 (mmHg)
Maximum Inlet Resistance of oil Pump with Clean Filter 150 (mmHg)
——END——

Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
