Fleetguard FS204968PMX Coarse Filter Cartridges

FS204968PMX coarse filter cartridges are dedicated front-line components for industrial fluid pre-treatment. Adopting durable polypropylene monofilament mesh composite filter media (PMX) and a deep-pleated structure, they precisely intercept contaminants such as sediment, rust, and large particles in liquids, significantly reducing the clogging risk of downstream precision filter elements.

The product is compatible with standard filter housings, featuring strong installation versatility, excellent acid and alkali resistance, anti-aging properties, and chemical compatibility, ensuring stable operation in harsh working conditions including petroleum, chemical, water treatment, and mechanical lubrication.

Its design balances high flow rate and low pressure drop, effectively improving system filtration efficiency and extending the service life of downstream equipment and filters, making it a reliable choice for industrial pre-treatment.

Advantages of  FS204968PMX Coarse Filter Cartridges

  • High-Efficiency Coarse Filtration Protection: Precisely captures large-particle impurities with stable filtration efficiency, providing reliable front-line protection for downstream precision components.

  • Low Pressure Drop & High Flow: The pleated structure greatly increases the filtration area with low flow resistance, adapting to high-flow working conditions and enhancing system operation efficiency.

  • Durability & Long Service Life: High dirt-holding capacity and strong chemical compatibility reduce replacement frequency and lower operation and maintenance costs.

  • Easy & Universal Installation: Standard size fits mainstream filter housings, featuring simple assembly and disassembly, excellent universality and compatibility, and adapting to various industrial scenarios.

Technical Specifications

Part Number:
FS204968PMX
Filter Type:Coarse Filter Cartridges
Dimensions:OD≈φ114.5mm,Total Height≈175mm
Connection SpecsThread Size: 1-14UNS-2B
Filtration Precision:20μm
Filtration Efficiency:≥98%
Applicable Models/Platforms:Cummins series, Sany Heavy Industry, etc.
Operating Conditions:Working pressure ≤ 0.6 MPa; Operating temperature -30℃ ~ +100℃
Lead Time:15 – 30 Working Days
Payment Terms:T/T ,L/C
your 360 images

Filter Model

Dimensions

Connection Specs

Filtration Precision

Filtration Efficiency

FS204968PMXOD≈φ114.5mm,Total Height≈175mmThread Specification: 1-14UNS-2B20μm≥98%
FS204798PMXOD≈φ110mm,Total Height≈195mmThread Specification: 1-14UNS-2B50μm≥99%
FS204788PMXOD≈φ110mm,Total Height≈238mmThread Specification: 1-14UNS-2B50μm≥99%
FS204008PMXOD≈φ129*21mm,Total Height≈243mmThread Specification: 1-14UNS-2B10μm≥98%
FS204048PMXOD≈φ129*21mm,Total Height≈119mm222/226 standard end30μm≥99%
FS204808PMXOD≈φ138.5mm,Total Height≈176mmThread Specification: M36×1.5-6H20μm≥95%
FS204438PMXOD≈φ136mm,Total Height≈351mmThread Specification: 11/2-12UNF-2B30μm≥98.5%
FS204448PMXOD≈φ108mm,Total Height≈299mmThread Specification: 1-14UNS-2B30μm≥98.5%
FS204458PMXOD≈φ108mm,Total Height≈318mmThread Specification: 1-14UNS-2B30μm≥99%
FS204468PMXOD≈φ113*22mm,Total Height≈145mm226 connection20μm≥95%
FS204478PMXOD≈φ112*16.8mm,Total Height≈247mmThread Specification: 1-14UNS-2B50μm≥99.5%
FS204728PMXOD≈φ133mm,Total Height≈252mmThread Specification: 1″-14UNS25μm≥95%
FS204708PMXOD≈φ133mm,Total Height≈248mmThread Specification: 1-14UNS-2B50μm≥99%
FS203598PMXOD≈φ129mm,Total Height≈244mmThread Specification: M16×1.510μm≥98%
FS203468PMXOD≈φ111mm,Total Height≈293mmThread Specification: 1-14UNS-2B30μm≥99%
FS203848PMXOD≈φ111mm,Total Height≈211mmThread Specification: 1-14UNS-2B10μm≥99.5%
FS203488PMXOD≈φ111mm,Total Height≈257mmThread Specification: M32X1.5-6H20μm≥99.5%
FS203408PMXOD≈φ124mm,Total Height≈262mmThread Specification: M16×1.530μm≥99.5%
FS203398PMXOD≈φ94mm,Total Height≈169mmThread Specification: 1-14UNS10μm≥98%
FS203838PMXOD≈φ111.5mm,Total Height≈231mmThread Specification: 1-14UNS-2B25μm≥99%
FS203478PMXOD≈φ111mm,Total Height≈319mmThread Specification: 1-14UNS-2B30μm≥98%
FS203298PMXOD≈φ137mm,Total Height≈334mmThread Specification: 1-3/8-16UNS-2B10μm≥98%
FS201578PMXOD≈φ111mm,Total Height≈268mmThread Specification: 1-14UNS-2B25μm≥98.5%
FS201978PMXOD≈φ111.5mm,Total Height≈239mmThread Specification: 1-14UNS-2B25μm≥99.5%
FS201808PMXOD≈φ108mm,Total Height≈231mmThread Specification: 1-14UNS-2B20μm≥95%
——END——

General Infomation of DCEC C220-10A Automotive Engine

Engine ModelC220-10AAdvertised Power220 HP @ 2400 RPM
Peak Torque780 N.m @ 1500 RPMCurve&DatasheetFR 91484
Fuel SystemBosch P7100 PumpNo. Of Cylinders6
AspirationTurbocharged & Air IntercoolerDisplacement8.3 L
Bore * Stroke114 mm * 135 mmCPL Code Revision8418
Dry Weight 617 kgWet Weight 636 kg
Compression Ratio17.3 : 1

Installation Data of DCEC C220-10A Automotive Engine

Center of Gravity. Distance From Front Face of Block427 mm
Center of Gravity. Distance Above Crank Centerline(Above Crankshaft)163 mm
Maximum Bending Moment At Rear Face of Block1356 N.m
Maximum Crankshaft Thrust Bearing load limit- Intermittent load3558 N
Maximum Crankshaft Thrust Bearing load limit-Continuous load2670 N
Instantaneous Inertia At Rotating: (Without Flywheel) N/A
Emissions CertificationGB17691/GB14761
Idle Speed800 RPM
Maximum Non-Load Speed2720 RPM
Over Speed Performance (Within 15 Seconds)3500 RPM
The Clutch Torque @ 800Rpm495 N.m
Maximum Altitude At Which Continuous operation Is Allowed3000 m
Supercharger outlet Exhaust Pressure limit Value 450 kPa
Maximum Power of Exhaust Brake114 kW
——END——

Engine Performance Data Rated power of DCEC C220-10A Automotive Drive Engine

Rated PowerTorque PeakRated PowerTorque Peak
Engine Speed2400 RPM1500 RPMExhaust Temperature625 ℃602 ℃
Oil Pressure345 kPa282 kPaFuel Consumption43 L/hr26.9 L/hr
The Air Flow18.9 m³/min9.1 m³/minCoolant FlowN/AN/A
The Flow Rate of Pressurized AirN/AN/AHeat Loss Coolant77 kW60 kW
Pressurized Air PressureN/AN/AHeat Loss Air46 kW14 kW
The Exhaust Flow45 m³/min21.3 m³/minMechanical Loss of PowerN/AN/A


System Technical Data of DCEC C220-10A Automotive Drive Engine

Air Intake SystemMaximum Temperature Rise Between Ambient Air and Engine Air Inlet15
Maximum Intake Restriction with Dry Type Air Cleaner,with Clean Filter-Medium Duty2.9 (300) kPa (mmH2O)
Maximum Intake Restriction with Dry Type Air Cleaner,with Clean Filter-Heavy Duty3.7 (380) kPa (mmH2O)
Maximum Intake Restriction with Dirty Filter6.2 (635) kPa (mmH2O)
Turbocharged & IntercooledMaximum Intake Manifold Temperature-Second Level55
Maximum Intake Manifold Temperature-Three-Level50
Intercooler Cooling Temperature-Second Level25
Intercooler Cooling Temperature-Three-Level20
Maximum Allowable Pressure Difference Before and After Intercooling-Three-Level16.7 (125) kPa(mmHg)
Minimum Inlet Pipe Diameter Allowed-Three-Level75 mm
Exhaust SystemMaximum Back Pressure Imposed by Complete Exhaust System10.0 (75) kPa (mmHg)
Exhaust Pipe Size Normally Accepable75 mm
Maximum Static Bend Allowed for Turbocharger Exhaust FlangeN/A
Lubrication SystemLow oil Level Inclination Angle-Front Up45 °
Low oil Level Inclination Angle-Back Up45 °
Low oil Level Inclination Angle-Fuel Pump Side Up45 °
Low oil Level Inclination Angle-Exhaust Side Up45 °
Oil Sump Capacity-Upper Limit14.2 L
Oil Sump Capacity-Lower Limit12.4 L
Capacity of The Whole System16.4 L
Cooling SystemCoolant Capacity – Engine only9 L
Standard Thermostat (Modulating) Range83 – 95
Minimum Fill Rate ( Without Low Level Alarm)19 L/min
Minimum Coolant Expansion Space – % of System Capacity6 %
Water Tank Capacity Without Water Expansion6 L
Maximum Coolant Pressure (Without Pressure Cap, Thermostat Closed)276 kPa
Maximum Degassing Time25 mins
Maximum Coolant Flow to Accessories41 L/min
Maximum Coolant Temperature Engine out100
Minimum Allows Pressure of Pressure Cap50 kPa
Minimum Recommended Coolant Temperature70
Common Operating Temperature Range of Fans with Fan Clutch93
Maximum Coolent Temperature For Engine Protection Control100
The Limit Environmental Temperature at Rated SpeedSecond Level 45 ;Three-Level 42
The Limit Environmental Temperature at Peak TorqueSecond Level 40 ;Three-Level 37
24V Electrical SystemMaximum Allowable Resistance of Cranking Circuit0.002
The Cold Start Current When Engine and The Clutch Separate12 V 500 24 V 250
Cold Starting SystemMaximum Unaided Cold Start Temperature120 RPM -10
Maximum Aided Cold Start Temperature110 RPM -35
Fuel SystemMaximum Fuel Return Resistance520 (mmHg)
Maximum Inlet Resistance of oil Pump with Clean Filter150 (mmHg)
——END——

Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
