Fleetguard FS36267B 00MX Oil-Water Separator

The FS36267B 00MX is a high-performance oil-water separator engineered by Fleetguard, dedicated to diesel engine fuel system protection for heavy-duty trucks, commercial vehicles and construction machinery. Adopting professional Stratapore filter paper and deep filtration media, it achieves precise oil-water separation and impurity removal, effectively purifying fuel and ensuring stable engine operation. It is a perfect original replacement part with standardized size and easy assembly, fully matching Cummins series engines and mainstream commercial vehicle platforms.

Equipped with an integrated transparent water collection cup, the product allows real-time observation of separated water volume, facilitating timely drainage and maintaining optimal working efficiency at all times. The built-in 200W PTC heater automatically adjusts heat output according to fuel temperature, preventing fuel waxing in low-temperature environments and greatly improving the cold start performance of engines in harsh working conditions.

The oil-water separator features a durable polymer water cup and high-seal gasket, with strong corrosion resistance against water, alcohol and mixed fuel additives. It has passed strict quality testing and obtained ISO 9001/TS 16949 certification, with a filtration efficiency of up to 97% and stable performance during long-term use, effectively reducing the failure rate of the fuel system.

Advantages of FS36267B 00MX Oil-Water Separator

  • High-Efficiency Filtration & Separation : Adopts Fleetguard’s proprietary Stratapore deep filtration media, realizing 97% high filtration efficiency and efficient oil-water separation. It can thoroughly remove impurities and free water in fuel, avoid abrasive wear of engine components, and extend the service life of the fuel injection system and engine.

  • Intelligent Low-Temperature Adaptation : The built-in 200W PTC electric heater with automatic temperature control function starts working when the fuel temperature is below 7°C and stops at 24°C. It effectively prevents diesel waxing and solidification in low-temperature environments, ensuring smooth fuel supply and reliable cold start of the engine in cold areas.

  • User-Friendly Design & Easy Maintenance : The transparent polymer water collection cup enables visual water level monitoring, eliminating blind drainage and fuel waste. The cup and drain valve are reusable, only the spin-on filter cartridge needs to be replaced during maintenance, which shortens the maintenance time and reduces the overall use cost of customers.

  • Durable Quality & Wide Compatibility : Made of high-corrosion-resistance polymer and metal materials, with a high-seal gasket for reliable sealing performance, it can adapt to various harsh working conditions of engineering machinery and commercial vehicles. It is fully compatible with Cummins series engines and mainstream heavy-duty truck platforms, and is an ideal original equipment replacement part with stable and reliable performance.

Technical Specifications

Part Number:FS36267B 00MX
Filter Type:Oil-Water Separator
Dimensions:Outer Diameter≈110mm, Overall Height≈230mm
Connection Specs:Thread Specification: 1-14 UNF
Filtration Precision:10μm
Filtration Efficiency:≥97% (ISO 4548 Standard)
Applicable Models/Platforms:Cummins Series Engines
Operating Conditions:-40℃~120℃
Lead Time:15 – 30 Working Days
Payment Terms:T/T ,L/C

Filter Model

Dimensions

Connection Specs

Filtration Precision

Filtration Efficiency

FS36267B 00MXOuter Diameter≈110mm, Overall Height≈230mmThread Specification: 1-14 UNF10μm≥97% (ISO 4548 Standard)
FS36263 00MXOuter Diameter≈95 mm, Overall Height≈210 mmThread Specification:M22×1.53 μm≥99% (ISO 4548 Standard)
FS36247 00MXOuter Diameter≈108 mm, Overall Height≈ 200 mmThread Specification: 1″-14 UN4 μm≥98% (ISO 4548 Standard)
FS36259 00MXOuter Diameter≈108.3 mm , Overall Height≈ 291 mmThread Specification:1″-14 UNF5 μm≥98% (ISO 4548 Standard)
FS36239 00MXOuter Diameter≈93 mm, Overall Height≈192 mmThread Specification: 1″-14 UNF4 μm≥97% (ISO 4548 Standard)
FS36240 00MXOuter Diameter≈116 mm, Overall Height≈178 mmThread Specification: M16 × 1.510μm≥98% (ISO 4548 Standard)
FS36233 00MXOuter Diameter≈93 mm, Overall Height≈174 mmThread Specification: M16×1.510 μm≥98% (ISO 4548 Standard)
FS36235 00MXOuter Diameter≈93 mm, Overall Height≈165 mmThread Specification: M16×1.510 μm≥98%(ISO 4548 Standard)
FS36235S 00MXOuter Diameter≈93 mm, Overall Height≈165 mmThread Specification: M16×1.510 μm≥98%(ISO 4548 Standard)
FS36239 00MXOuter Diameter≈93 mm, Overall Height≈174 mmThread Specification: M16×1.510 μm≥98% (ISO 4548 Standard)
FS36209 00MXOuter Diameter≈93 mm, Overall Height≈200 mmThread Specification: M20×1.54 μm≥98% (ISO 4548 Standard)
FS36210 00MXOuter Diameter≈111mm, Overall Height≈256mmThread Specification: 1″-14 UNF10μm≥97% (ISO 4548 Standard)
FS36234 B-AA 00MXOuter Diameter≈110mm, Overall Height≈245mmThread Specification:1″-14 UNF10μm≥97% (ISO 4548 Standard)
FS36234 00MXOuter Diameter≈110mm, Overall Height≈240mmThread Specification:1″-14 UNF10μm≥97%(ISO 4548 Standard)
FS36267 00MXOuter Diameter≈110mm, Overall Height≈235mmThread Specification: 1″-14 UNF10μm≥97%(ISO 4548 Standard)
FS36277 00MXOuter Diameter≈112mm, Overall Height≈240mmThread Specification: 1″-14 UNF10μm≥97% (ISO 4548 Standard)
FS36204 00MXOuter Diameter≈108mm, Overall Height≈228mmThread Specification: 1″-14 UNF10μm≥97% (ISO 4548 Standard)
FS36229 00MXOuter Diameter≈82.7mm, Overall Height≈176mmThread Specification: 3/4-16 UNF-2B Thread5μm≥99% (ISO 4548 Standard)
FS36248Outer Diameter≈95mm, Overall Height≈210mmThread Specification: 1-14 UNF-2B Thread5μm≥99% (ISO 4548 Standard)
FS36249Outer Diameter≈110mm, Overall Height≈285mmThread Specification: M18×1.55μm99.9% (ISO 4548 Standard)
FS36261Outer Diameter≈115mm, Overall Height≈300mmThread Specification: M20×1.55μm99.9% (ISO 4548 Standard)
FS36215Outer Diameter≈120mm, Overall Height≈320mmThread Specification: M18×1.55μm99.9% (ISO 4548 Standard)
FS36279Outer Diameter≈118mm, Overall Height≈295mmThread Specification:M18×1.55μm99.9% (ISO 4548 Standard)
——END——

General Infomation of DCEC C220-10A Automotive Engine

Engine ModelC220-10AAdvertised Power220 HP @ 2400 RPM
Peak Torque780 N.m @ 1500 RPMCurve&DatasheetFR 91484
Fuel SystemBosch P7100 PumpNo. Of Cylinders6
AspirationTurbocharged & Air IntercoolerDisplacement8.3 L
Bore * Stroke114 mm * 135 mmCPL Code Revision8418
Dry Weight 617 kgWet Weight 636 kg
Compression Ratio17.3 : 1

Installation Data of DCEC C220-10A Automotive Engine

Center of Gravity. Distance From Front Face of Block427 mm
Center of Gravity. Distance Above Crank Centerline(Above Crankshaft)163 mm
Maximum Bending Moment At Rear Face of Block1356 N.m
Maximum Crankshaft Thrust Bearing load limit- Intermittent load3558 N
Maximum Crankshaft Thrust Bearing load limit-Continuous load2670 N
Instantaneous Inertia At Rotating: (Without Flywheel) N/A
Emissions CertificationGB17691/GB14761
Idle Speed800 RPM
Maximum Non-Load Speed2720 RPM
Over Speed Performance (Within 15 Seconds)3500 RPM
The Clutch Torque @ 800Rpm495 N.m
Maximum Altitude At Which Continuous operation Is Allowed3000 m
Supercharger outlet Exhaust Pressure limit Value 450 kPa
Maximum Power of Exhaust Brake114 kW
——END——

Engine Performance Data Rated power of DCEC C220-10A Automotive Drive Engine

Rated PowerTorque PeakRated PowerTorque Peak
Engine Speed2400 RPM1500 RPMExhaust Temperature625 ℃602 ℃
Oil Pressure345 kPa282 kPaFuel Consumption43 L/hr26.9 L/hr
The Air Flow18.9 m³/min9.1 m³/minCoolant FlowN/AN/A
The Flow Rate of Pressurized AirN/AN/AHeat Loss Coolant77 kW60 kW
Pressurized Air PressureN/AN/AHeat Loss Air46 kW14 kW
The Exhaust Flow45 m³/min21.3 m³/minMechanical Loss of PowerN/AN/A


System Technical Data of DCEC C220-10A Automotive Drive Engine

Air Intake SystemMaximum Temperature Rise Between Ambient Air and Engine Air Inlet15
Maximum Intake Restriction with Dry Type Air Cleaner,with Clean Filter-Medium Duty2.9 (300) kPa (mmH2O)
Maximum Intake Restriction with Dry Type Air Cleaner,with Clean Filter-Heavy Duty3.7 (380) kPa (mmH2O)
Maximum Intake Restriction with Dirty Filter6.2 (635) kPa (mmH2O)
Turbocharged & IntercooledMaximum Intake Manifold Temperature-Second Level55
Maximum Intake Manifold Temperature-Three-Level50
Intercooler Cooling Temperature-Second Level25
Intercooler Cooling Temperature-Three-Level20
Maximum Allowable Pressure Difference Before and After Intercooling-Three-Level16.7 (125) kPa(mmHg)
Minimum Inlet Pipe Diameter Allowed-Three-Level75 mm
Exhaust SystemMaximum Back Pressure Imposed by Complete Exhaust System10.0 (75) kPa (mmHg)
Exhaust Pipe Size Normally Accepable75 mm
Maximum Static Bend Allowed for Turbocharger Exhaust FlangeN/A
Lubrication SystemLow oil Level Inclination Angle-Front Up45 °
Low oil Level Inclination Angle-Back Up45 °
Low oil Level Inclination Angle-Fuel Pump Side Up45 °
Low oil Level Inclination Angle-Exhaust Side Up45 °
Oil Sump Capacity-Upper Limit14.2 L
Oil Sump Capacity-Lower Limit12.4 L
Capacity of The Whole System16.4 L
Cooling SystemCoolant Capacity – Engine only9 L
Standard Thermostat (Modulating) Range83 – 95
Minimum Fill Rate ( Without Low Level Alarm)19 L/min
Minimum Coolant Expansion Space – % of System Capacity6 %
Water Tank Capacity Without Water Expansion6 L
Maximum Coolant Pressure (Without Pressure Cap, Thermostat Closed)276 kPa
Maximum Degassing Time25 mins
Maximum Coolant Flow to Accessories41 L/min
Maximum Coolant Temperature Engine out100
Minimum Allows Pressure of Pressure Cap50 kPa
Minimum Recommended Coolant Temperature70
Common Operating Temperature Range of Fans with Fan Clutch93
Maximum Coolent Temperature For Engine Protection Control100
The Limit Environmental Temperature at Rated SpeedSecond Level 45 ;Three-Level 42
The Limit Environmental Temperature at Peak TorqueSecond Level 40 ;Three-Level 37
24V Electrical SystemMaximum Allowable Resistance of Cranking Circuit0.002
The Cold Start Current When Engine and The Clutch Separate12 V 500 24 V 250
Cold Starting SystemMaximum Unaided Cold Start Temperature120 RPM -10
Maximum Aided Cold Start Temperature110 RPM -35
Fuel SystemMaximum Fuel Return Resistance520 (mmHg)
Maximum Inlet Resistance of oil Pump with Clean Filter150 (mmHg)
——END——

Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
