Fleetguard LF17559 Oil Filter

LF17559 is a heavy-duty spin-on oil filter by Fleetguard, exclusively designed for Cummins ISG 11.8L/12.9L and ISX 15L heavy-duty diesel engines and widely applied in Foton Auman GTL/ETX 430-550HP heavy trucks, Daimler commercial vehicles, long-haul logistics tractors, and large construction machinery. It adopts Fleetguard’s advanced StrataPore™ high-efficiency composite filter media, achieving 99% filtration efficiency at 20 microns to capture ultra-fine metal particles, carbon residues, and oil contaminants generated by high-power engines, effectively protecting crankshafts, camshafts, and turbochargers from premature wear.

Key specifications: 120mm outer diameter, 399mm height, and 1-1/2″-12UNF-2B thread specification with a 112mm outer seal diameter, perfectly matching original mounting positions. It supports tool-assisted quick installation and maintains stable performance in -40°C to 135°C extreme temperature ranges.

As an OEM-grade replacement for Cummins 3694654, it provides reliable lubrication system protection for high-load long-haul operations and heavy construction tasks, supporting 80,000km+ extended service intervals and reducing maintenance frequency for mixed fleet operations.

Advantages of  LF17559 Oil Filter

  • Dual-Engine Compatibility: Exclusively fits both Cummins ISG and ISX engines, solving the problem of filter mismatch in mixed fleet operations with both engine types, reducing inventory costs by 40%+.

  • StrataPore™ Composite Filtration: 20-micron precision captures 99% of contaminants, extending engine overhaul cycle by 25% and reducing long-term maintenance costs for heavy trucks and construction machinery.

  • Ultra-Long Service Life: 2.5X higher dirt-holding capacity than standard filters, supporting 80,000km+ service intervals ideal for cross-regional logistics and remote construction sites with limited maintenance resources.

  • Extreme Temperature & Pressure Resistance: Stable operation from -40°C to 135°C adapts to alpine regions and desert high-temperature environments; reinforced steel housing withstands 10bar oil pressure, eliminating deformation risks.

  • Cost-Effective Heavy-Duty Solution: Directly replaces 3694654 OEM parts, offering equivalent performance to original filters at 20% lower cost, while its extended service life further reduces total ownership costs for fleet operators.

Technical Specifications

Part Number: LF17559
Filter Type: Spin-On Oil Filter
Dimensions: OD≈φ120.65mm, Total Height≈399.7mm
Connection Specs Thread Specification: 1-1/8″-16 UN-2B
Filtration Precision: 20μm
Filtration Efficiency: ≥98% (ISO 4548 Standard)
Applicable Models/Platforms: Compatible with Cummins ISG11, ISG12, ISX series heavy-duty engines
Operating Conditions: Temp: -40~120℃; Pressure: ≤10bar;
Lead Time: 15 – 30 Working Days
Payment Terms: T/T ,L/C

coming soon

coming soon

coming soon

Engine Model

Dimensions

Connection Specs

Filtration Precision

Filtration Efficiency

LF17559 OD≈φ120.65mm, Total Height≈399.7mm Thread Specification: 1-1/8″-16 UN-2B 20μm ≥98% (ISO 4548 Standard)
LF14004 NN OD≈φ122.5mm, Total Height≈235mm Thread Specification: 1-1/8″-16 UN-2B 20μm ≥98% (ISO 4548 Standard)
LF16403 OD≈φ122.5mm, Total Height≈229mm Thread Specification: 1-1/8″-16 UN-2B 20μm ≥98% (ISO 4548 Standard)
LF17579 OD≈φ122mm, Total Height≈249mm Thread Specification: 1-1/8″-16 UN-2B 20μm ≥98% (ISO 4548 Standard)
LF16016 OD≈φ95.6mm, Total Height≈175mm Thread Specification: M22×1.5 20μm ≥98% (ISO 4548 Standard)
LF16352 OD≈φ101mm, Total Height≈175mm Thread Specification: M27×2 30μm ≥98% (ISO 4548 Standard)
LF16396 OD≈φ108mm, Total Height≈165mm Thread Specification: M24×1.5 20μm ≥98% (ISO 4548 Standard)
LF17356 OD≈φ102mm, Total Height≈158mm Thread Specification: M67×4 SPECIAL BUTT 20μm ≥98% (ISO 4548 Standard)
LF17535 OD≈φ108mm, Total Height≈165mm Thread Specification: M24×1.5 20μm ≥98% (ISO 4548 Standard)
LF16507 OD≈φ95mm, Total Height≈155mm Thread Specification: M20×1.5 20μm ≥98% (ISO 4548 Standard)
LF17816 OD≈φ102mm, Total Height≈250mm Thread Specification: M22×1.5 20μm ≥98% (ISO 4548 Standard)
LF16394 OD≈φ95mm, Total Height≈140mm Thread Specification: M20×1.5 20μm ≥98% (ISO 4548 Standard)
LF16514 OD≈φ95mm, Total Height≈150mm Thread Specification: M20×1.5 20μm ≥98% (ISO 4548 Standard)
LF17815 OD≈φ102mm, Total Height≈145mm Thread Specification: M22×1.5 20μm ≥98% (ISO 4548 Standard)
LF16422 OD≈φ95mm, Total Height≈170mm Thread Specification: M20×1.5 20μm ≥98% (ISO 4548 Standard)
LF14000 OD≈φ120.3mm, Total Height≈294.69mm Thread Specification: M95×2.5-6H INT 20μm ≥97% (ISO 4548 Standard)
LF16015 OD≈φ116mm, Total Height≈152mm Thread Specification: M24×1.5 20μm ≥98% (ISO 4548 Standard)
LF16034 OD≈φ84mm, Total Height≈89mm Thread Specification: M22×1.5 15μm ≥98% (ISO 4548 Standard)
LF17356-FGC OD≈φ101mm, Total Height≈158mm Thread Specification: M20×1.5 15μm ≥98% (ISO 4548 Standard)
LF16011 00MX OD≈φ105mm, Total Height≈250mm Thread Specification: M20×1.5 15μm ≥98% (ISO 4548 Standard)
LF16013 00MX OD≈φ105mm, Total Height≈252mm Thread Specification: M20×1.5 15μm ≥98% (ISO 4548 Standard)
LF16329 00MX OD≈φ115mm, Total Height≈278mm Thread Specification: M20×1.5 15μm ≥98% (ISO 4548 Standard)
LF16119 00MX OD≈φ110mm, Total Height≈265mm Thread Specification: M20×1.5 15μm ≥98% (ISO 4548 Standard)
LF16112 00MX OD≈φ108mm, Total Height≈258mm Thread Specification: M20×1.5 15μm ≥98% (ISO 4548 Standard)
LF16008 00MX OD≈φ105mm, Total Height≈250mm Thread Specification: M20×1.5 15μm ≥98% (ISO 4548 Standard)
LF16294 00MX OD≈φ112mm, Total Height≈270mm Thread Specification: M20×1.5 15μm ≥98% (ISO 4548 Standard)
LF16333 00MX OD≈φ118mm, Total Height≈280mm Thread Specification: M20×1.5 15μm ≥98% (ISO 4548 Standard)
LF16327 00MX OD≈φ115mm, Total Height≈275mm Thread Specification: M22×1.5 15μm ≥98% (ISO 4548 Standard)
LF17500 00MX OD≈φ120mm, Total Height≈290mm Thread Specification: M20×1.5 15μm ≥98% (ISO 4548 Standard)
LF17500 00MF OD≈φ120mm, Total Height≈290mm Thread Specification: M22×1.5 15μm ≥98% (ISO 4548 Standard)
LF16045 OD≈φ105mm, Total Height≈252mm Thread Specification: M20×1.5 15μm ≥98% (ISO 4548 Standard)
LF16175 00MX OD≈φ110mm, Total Height≈268mm Thread Specification: M22×1.5 15μm ≥98% (ISO 4548 Standard)
LF16326 00MX OD≈φ112mm, Total Height≈272mm Thread Specification: M20×1.5 15μm ≥98% (ISO 4548 Standard)
LF16011 OD≈φ105mm, Total Height≈250mm Thread Specification: M22×1.5 15μm ≥98% (ISO 4548 Standard)
——END——

General Infomation of DCEC C220-10A Automotive Engine

Engine Model C220-10A Advertised Power 220 HP @ 2400 RPM
Peak Torque 780 N.m @ 1500 RPM Curve&Datasheet FR 91484
Fuel System Bosch P7100 Pump No. Of Cylinders 6
Aspiration Turbocharged & Air Intercooler Displacement 8.3 L
Bore * Stroke 114 mm * 135 mm CPL Code Revision 8418
Dry Weight  617 kg Wet Weight  636 kg
Compression Ratio 17.3 : 1

Installation Data of DCEC C220-10A Automotive Engine

Center of Gravity. Distance From Front Face of Block 427 mm
Center of Gravity. Distance Above Crank Centerline(Above Crankshaft) 163 mm
Maximum Bending Moment At Rear Face of Block 1356 N.m
Maximum Crankshaft Thrust Bearing load limit- Intermittent load 3558 N
Maximum Crankshaft Thrust Bearing load limit-Continuous load 2670 N
Instantaneous Inertia At Rotating: (Without Flywheel)  N/A
Emissions Certification GB17691/GB14761
Idle Speed 800 RPM
Maximum Non-Load Speed 2720 RPM
Over Speed Performance (Within 15 Seconds) 3500 RPM
The Clutch Torque @ 800Rpm 495 N.m
Maximum Altitude At Which Continuous operation Is Allowed 3000 m
Supercharger outlet Exhaust Pressure limit Value  450 kPa
Maximum Power of Exhaust Brake 114 kW
——END——

Engine Performance Data Rated power of DCEC C220-10A Automotive Drive Engine

Rated Power Torque Peak Rated Power Torque Peak
Engine Speed 2400 RPM 1500 RPM Exhaust Temperature 625 ℃ 602 ℃
Oil Pressure 345 kPa 282 kPa Fuel Consumption 43 L/hr 26.9 L/hr
The Air Flow 18.9 m³/min 9.1 m³/min Coolant Flow N/A N/A
The Flow Rate of Pressurized Air N/A N/A Heat Loss Coolant 77 kW 60 kW
Pressurized Air Pressure N/A N/A Heat Loss Air 46 kW 14 kW
The Exhaust Flow 45 m³/min 21.3 m³/min Mechanical Loss of Power N/A N/A


System Technical Data of DCEC C220-10A Automotive Drive Engine

Air Intake System Maximum Temperature Rise Between Ambient Air and Engine Air Inlet 15 ℃
Maximum Intake Restriction with Dry Type Air Cleaner,with Clean Filter-Medium Duty 2.9 (300) kPa (mmH2O)
Maximum Intake Restriction with Dry Type Air Cleaner,with Clean Filter-Heavy Duty 3.7 (380) kPa (mmH2O)
Maximum Intake Restriction with Dirty Filter 6.2 (635) kPa (mmH2O)
Turbocharged & Intercooled Maximum Intake Manifold Temperature-Second Level 55 ℃
Maximum Intake Manifold Temperature-Three-Level 50 ℃
Intercooler Cooling Temperature-Second Level 25 ℃
Intercooler Cooling Temperature-Three-Level 20 ℃
Maximum Allowable Pressure Difference Before and After Intercooling-Three-Level 16.7 (125) kPa(mmHg)
Minimum Inlet Pipe Diameter Allowed-Three-Level 75 mm
Exhaust System Maximum Back Pressure Imposed by Complete Exhaust System 10.0 (75) kPa (mmHg)
Exhaust Pipe Size Normally Accepable 75 mm
Maximum Static Bend Allowed for Turbocharger Exhaust Flange N/A
Lubrication System Low oil Level Inclination Angle-Front Up 45 °
Low oil Level Inclination Angle-Back Up 45 °
Low oil Level Inclination Angle-Fuel Pump Side Up 45 °
Low oil Level Inclination Angle-Exhaust Side Up 45 °
Oil Sump Capacity-Upper Limit 14.2 L
Oil Sump Capacity-Lower Limit 12.4 L
Capacity of The Whole System 16.4 L
Cooling System Coolant Capacity – Engine only 9 L
Standard Thermostat (Modulating) Range 83 – 95 ℃
Minimum Fill Rate ( Without Low Level Alarm) 19 L/min
Minimum Coolant Expansion Space – % of System Capacity 6 %
Water Tank Capacity Without Water Expansion 6 L
Maximum Coolant Pressure (Without Pressure Cap, Thermostat Closed) 276 kPa
Maximum Degassing Time 25 mins
Maximum Coolant Flow to Accessories 41 L/min
Maximum Coolant Temperature Engine out 100 ℃
Minimum Allows Pressure of Pressure Cap 50 kPa
Minimum Recommended Coolant Temperature 70 ℃
Common Operating Temperature Range of Fans with Fan Clutch 93 ℃
Maximum Coolent Temperature For Engine Protection Control 100 ℃
The Limit Environmental Temperature at Rated Speed Second Level 45 ℃;Three-Level 42 ℃
The Limit Environmental Temperature at Peak Torque Second Level 40 ℃;Three-Level 37 ℃
24V Electrical System Maximum Allowable Resistance of Cranking Circuit 0.002 Ω
The Cold Start Current When Engine and The Clutch Separate 12 V 500 24 V 250
Cold Starting System Maximum Unaided Cold Start Temperature 120 RPM -10 ℃
Maximum Aided Cold Start Temperature 110 RPM -35 ℃
Fuel System Maximum Fuel Return Resistance 520 (mmHg)
Maximum Inlet Resistance of oil Pump with Clean Filter 150 (mmHg)
——END——

Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
