Fleetguard TF150958PMX Transmission Filter

The TF150958PMX is a high-performance transmission filter engineered to protect heavy-duty automatic transmission systems. It efficiently removes harmful contaminants including metal shavings, clutch debris, and sludge, safeguarding valves, solenoids, bearings, and gear sets from abrasion and premature failure. Built with premium multi-layer media, it delivers stable filtration and consistent fluid flow under demanding operating conditions.

This filter features a robust, precision-built design with reliable sealing and optimized flow geometry. It is engineered to match OEM specifications for direct fitment, supporting easy installation and dependable operation in commercial trucks, buses, and industrial equipment. Its sturdy construction resists pressure fluctuations and vibration for long-term integrity.

By maintaining clean transmission fluid, the TF150958PMX supports smooth shifting, extends component life, and reduces unplanned downtime. It helps lower operating costs and preserve transmission reliability for fleets and heavy-duty applications.

Advantages of TF150958PMX Transmission Filter

  • The TF150958PMX uses high-efficiency filter media that captures both large and micro-sized particles. It effectively blocks abrasive debris that causes wear to precision transmission parts, preserving fluid cleanliness and ensuring stable, responsive shifting throughout service life.

  • With a carefully designed pleated structure, the filter delivers high dirt-holding capacity while minimizing pressure loss. Stable fluid flow supports consistent hydraulic control, improves transmission responsiveness, and reduces stress on pumps and seals during operation.

  • Built for harsh working environments, this filter features reinforced layers and leak-resistant gaskets to withstand vibration, high pressure, and temperature changes. Its robust design eliminates bypass and leaks, ensuring consistent protection in tough duty cycles.

  • Precision dimensions ensure perfect fitment with original equipment housings, eliminating installation errors. Extended service life reduces replacement frequency, cutting labor and parts expenses while protecting high-value transmission systems.

Technical Specifications

Part Number: TF150958PMX
Filter Type: Transmission Filter
Dimensions: Outer Diameter≈92mm, Overall Height≈178mm
Connection Specs: Thread Specification: M16×1.5
Filtration Precision: 10μm
Filtration Efficiency: ≥99.5% (ISO 4548 Standard)
Applicable Models/Platforms: Heavy-duty Commercial Vehicles, Construction Machinery Transmissions
Operating Conditions: High Temp, High Pressure, Heavy-duty Transmission Service
Lead Time: 15 – 30 Working Days
Payment Terms: T/T ,L/C

Coming soon

Coming soon

Coming soon

Filter Model

Dimensions

Connection Specs

Filtration Precision

Filtration Efficiency

TF150958PMX Outer Diameter≈92mm, Overall Height≈178mm Thread Specification: M16×1.5 10μm ≥99.5% (ISO 4548 Standard)
HF6190 Outer Diameter≈76mm, Overall Height≈165mm Thread Specification: M42×2 10μm ≥99.5% (ISO 4548 Standard)
HF7520 Outer Diameter≈86mm, Overall Height≈185mm Thread Specification: M42×2 10μm ≥99.5% (ISO 4548 Standard)
NG5910 Outer Diameter≈95mm, Overall Height≈ 244mm    Thread Specification: 1-1/2″-16 UN-2B standard spin-on thread 5μm ≥99.99% (ISO 4548 Standard)
UF001188PMX Outer Diameter≈65mm, Overall Height≈145mm Thread Specification: M30×1.5 5μm ≥99.8% (ISO 4548 Standard)
——END——

General Infomation of DCEC C220-10A Automotive Engine

Engine Model C220-10A Advertised Power 220 HP @ 2400 RPM
Peak Torque 780 N.m @ 1500 RPM Curve&Datasheet FR 91484
Fuel System Bosch P7100 Pump No. Of Cylinders 6
Aspiration Turbocharged & Air Intercooler Displacement 8.3 L
Bore * Stroke 114 mm * 135 mm CPL Code Revision 8418
Dry Weight  617 kg Wet Weight  636 kg
Compression Ratio 17.3 : 1

Installation Data of DCEC C220-10A Automotive Engine

Center of Gravity. Distance From Front Face of Block 427 mm
Center of Gravity. Distance Above Crank Centerline(Above Crankshaft) 163 mm
Maximum Bending Moment At Rear Face of Block 1356 N.m
Maximum Crankshaft Thrust Bearing load limit- Intermittent load 3558 N
Maximum Crankshaft Thrust Bearing load limit-Continuous load 2670 N
Instantaneous Inertia At Rotating: (Without Flywheel)  N/A
Emissions Certification GB17691/GB14761
Idle Speed 800 RPM
Maximum Non-Load Speed 2720 RPM
Over Speed Performance (Within 15 Seconds) 3500 RPM
The Clutch Torque @ 800Rpm 495 N.m
Maximum Altitude At Which Continuous operation Is Allowed 3000 m
Supercharger outlet Exhaust Pressure limit Value  450 kPa
Maximum Power of Exhaust Brake 114 kW
——END——

Engine Performance Data Rated power of DCEC C220-10A Automotive Drive Engine

Rated Power Torque Peak Rated Power Torque Peak
Engine Speed 2400 RPM 1500 RPM Exhaust Temperature 625 ℃ 602 ℃
Oil Pressure 345 kPa 282 kPa Fuel Consumption 43 L/hr 26.9 L/hr
The Air Flow 18.9 m³/min 9.1 m³/min Coolant Flow N/A N/A
The Flow Rate of Pressurized Air N/A N/A Heat Loss Coolant 77 kW 60 kW
Pressurized Air Pressure N/A N/A Heat Loss Air 46 kW 14 kW
The Exhaust Flow 45 m³/min 21.3 m³/min Mechanical Loss of Power N/A N/A


System Technical Data of DCEC C220-10A Automotive Drive Engine

Air Intake System Maximum Temperature Rise Between Ambient Air and Engine Air Inlet 15 ℃
Maximum Intake Restriction with Dry Type Air Cleaner,with Clean Filter-Medium Duty 2.9 (300) kPa (mmH2O)
Maximum Intake Restriction with Dry Type Air Cleaner,with Clean Filter-Heavy Duty 3.7 (380) kPa (mmH2O)
Maximum Intake Restriction with Dirty Filter 6.2 (635) kPa (mmH2O)
Turbocharged & Intercooled Maximum Intake Manifold Temperature-Second Level 55 ℃
Maximum Intake Manifold Temperature-Three-Level 50 ℃
Intercooler Cooling Temperature-Second Level 25 ℃
Intercooler Cooling Temperature-Three-Level 20 ℃
Maximum Allowable Pressure Difference Before and After Intercooling-Three-Level 16.7 (125) kPa(mmHg)
Minimum Inlet Pipe Diameter Allowed-Three-Level 75 mm
Exhaust System Maximum Back Pressure Imposed by Complete Exhaust System 10.0 (75) kPa (mmHg)
Exhaust Pipe Size Normally Accepable 75 mm
Maximum Static Bend Allowed for Turbocharger Exhaust Flange N/A
Lubrication System Low oil Level Inclination Angle-Front Up 45 °
Low oil Level Inclination Angle-Back Up 45 °
Low oil Level Inclination Angle-Fuel Pump Side Up 45 °
Low oil Level Inclination Angle-Exhaust Side Up 45 °
Oil Sump Capacity-Upper Limit 14.2 L
Oil Sump Capacity-Lower Limit 12.4 L
Capacity of The Whole System 16.4 L
Cooling System Coolant Capacity – Engine only 9 L
Standard Thermostat (Modulating) Range 83 – 95 ℃
Minimum Fill Rate ( Without Low Level Alarm) 19 L/min
Minimum Coolant Expansion Space – % of System Capacity 6 %
Water Tank Capacity Without Water Expansion 6 L
Maximum Coolant Pressure (Without Pressure Cap, Thermostat Closed) 276 kPa
Maximum Degassing Time 25 mins
Maximum Coolant Flow to Accessories 41 L/min
Maximum Coolant Temperature Engine out 100 ℃
Minimum Allows Pressure of Pressure Cap 50 kPa
Minimum Recommended Coolant Temperature 70 ℃
Common Operating Temperature Range of Fans with Fan Clutch 93 ℃
Maximum Coolent Temperature For Engine Protection Control 100 ℃
The Limit Environmental Temperature at Rated Speed Second Level 45 ℃;Three-Level 42 ℃
The Limit Environmental Temperature at Peak Torque Second Level 40 ℃;Three-Level 37 ℃
24V Electrical System Maximum Allowable Resistance of Cranking Circuit 0.002 Ω
The Cold Start Current When Engine and The Clutch Separate 12 V 500 24 V 250
Cold Starting System Maximum Unaided Cold Start Temperature 120 RPM -10 ℃
Maximum Aided Cold Start Temperature 110 RPM -35 ℃
Fuel System Maximum Fuel Return Resistance 520 (mmHg)
Maximum Inlet Resistance of oil Pump with Clean Filter 150 (mmHg)
——END——

Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
