PARTMAC LF/Oil Filter
The LF series lube filter (LF stands for Lube Filter) is a high-end protective accessory launched by Fleetguard for medium and heavy-duty commercial vehicles and engineering machinery. It is fully compatible with premium heavy-duty truck platforms such as FX and GTL, as well as power systems of renowned brands like Caterpillar and John Deere, and supports National V and National VI high-pressure common rail engines.
Adopting phenolic resin-impregnated composite filter media, it can accurately capture 5-30 micron harmful impurities including metal debris and oil sludge with a filtration efficiency of over 99%, providing powerful protection for precision components such as crankshafts and camshafts. Its full-flow design with a built-in bypass valve ensures continuous oil supply during cold starts or filter clogging, while the large dust holding capacity extends the maintenance cycle.
Featuring a user-friendly spin-on structure, it resists extreme temperatures and vibrations, ideal for harsh working conditions like long-haul transportation and engineering operations. Covering various models including LF3472 and LF3379 to meet installation needs of different equipment, the LF3 series effectively reduces engine failure risks and prolongs the overall service life of machinery, serving as an optimal protection solution for the lubrication system of heavy-duty equipment.
General Specifications of LF Series
| Series: | LF Series |
| Filter Type: | Heavy-duty Spin-on Diesel Engine Oil Filter |
| Dimensions: | OD≈φ83-135mm, Total Height≈100-352mm |
| Thread Specification: | 1 1/8-16 UN-2B , M20×1.5-6H INT |
| Filtration Precision: | 20-30μm |
| Filtration Efficiency: | ≥98% (ISO 4548 Standard) |
| Applicable Models/Platforms: | Cummins series engines, etc. |
| Operating Conditions: | Turbocharged & Temp: -40~120℃; Pressure: ≤12bar; Flow rate: ≥25-50L/h; |
Part Name | Filtration Precision | Filtration Efficiency | Part Name | Filtration Precision | Filtration Efficiency | ||
| L131-030-AM 00MX | 20μm | ≥98% (ISO 4548 Standard) | LF3970 | 30μm | ≥98% (ISO 4548 Standard) | ||
| LF3764 | 30μm | ≥98% (ISO 4548 Standard) | LF3716 | 30μm | ≥95% (ISO 4548 Standard) | ||
| LF3321 | 25μm | ≥98% (ISO 4548 Standard) | LF3806 | 30μm | ≥98% (ISO 4548 Standard) | ||
| LF691A | 30μm | ≥95% (ISO 4548 Standard) | LF9050 | 30μm | ≥98% (ISO 4548 Standard) | ||
| LF9070 | 30μm | ≥98% (ISO 4548 Standard) | LF9009 | 30μm | ≥98% (ISO 4548 Standard) | ||
| LF3349 | 30μm | ≥95% (ISO 4548 Standard) | |||||
| ——END—— | |||||||
PARTMAC LF Series Oil Filter
This is the list of all series of PARTMAC LF Series Oil Filter.
Click here to find Oil Filter by type
Fleetguard L131-030-AM 00MX Oil Filter
Fleetguard Filters | L131-030-AM 00MX Oil Filter
Applicable Series: Chaoyang Diesel (CY4102/CY4105/CY4108 electronic injection), JAC Heavy Duty Diesel Engine
Part Name: L131-030-AM 00MX Oil Filter
Part Number: Original Equipment OE Number: Chaoyang Diesel 30.14.10, JAC NDG.30.14.10, Ankai Baoshitong 00MX
Applicable Platforms: Suitable for Chaoyang Diesel CY4102/CY4105/CY4108 electronic injection
Fleetguard LF3349 Oil Filter
Fleetguard Filters | LF3349 Oil Filter
Applicable Series: Cummins 6B/6BT/6BTA5.9, Case International Maxxum Series
Part Name: LF3349 Oil Filter
Part Number: Original Equipment OE Number: Cummins 3932217
Applicable Platforms: Suitable for Cummins 6B/6BT/6BTA5.9
Fleetguard LF9009 Oil Filter
Fleetguard Filters | LF9009 Oil Filter
Applicable Series: Cummins N14/L9/ISX, John Deere 6000/7000 Series, Sisu Diesel Heavy Duty Diesel Engine
Part Name: LF9009 Oil Filter
Part Number: Original Equipment OE Number: Cummins 3401544
Applicable Platforms: Suitable for Cummins N14/L9/ISX
Fleetguard LF9070 Oil Filter
Fleetguard Filters | LF9070 Oil Filter
Applicable Series: Cummins ISX15/QSX15, John Deere 7000 Series, Case International & New Holland Heavy Duty Diesel Engine
Part Name: LF9070 Oil Filter
Part Number: Original Equipment OE Number: Cummins 2882673/3101868/3406810
Applicable Platforms: Suitable for Cummins ISX15/QSX15, etc
Fleetguard LF9050 Oil Filter
Fleetguard Filters | LF9050 Oil Filter
Applicable Series: Cummins 4920071, Komatsu BF5209, Hitachi & Caterpillar Heavy Duty Diesel Engine
Part Name: LF9050 Oil Filter
Part Number: Original Equipment OE Number: Cummins 4920071, Komatsu BF5209
Applicable Platforms: Suitable for Cummins 4920071
Fleetguard LF691A Oil Filter
Fleetguard Filters | LF691A Oil Filter
Applicable Series: Caterpillar C10/C12/C15/3406/3408/3412/3508/3512/3516 Heavy Duty Diesel Engine
Part Name: LF691A Oil Filter
Part Number: Original Equipment OE Number: Caterpillar 1R-0716/2P-4005/1R-1808, Clark TL2FSO, Atlas Copco 52183233/3222317948
Applicable Platforms: Suitable for Caterpillar C10/C12/C15/3406/3408/3412/3508/3512/3516 series engines
Fleetguard LF3806 Oil Filter
Fleetguard Filters | LF3806 Oil Filter
Applicable Series: Cummins 4BT3.9/6BT5.9, Case International Maxxum, New Holland, JCB, Hyundai, Ingersoll-Rand Heavy Duty Diesel Engine
Part Name: LF3806 Oil Filter
Part Number: Original Equipment OE Number: Cummins 3934430
Applicable Platforms: Suitable for Cummins 4BT3.9/6BT5.9
Fleetguard LF3321 Oil Filter
Fleetguard Filters | LF3321 Oil Filter
Applicable Series: Volvo, Renault, Mack Heavy Duty Diesel Engine
Part Name: LF3321 Oil Filter
Part Number: Original Equipment OE Number: Volvo 466634-3/478736, Ingersoll-Rand 85401909
Applicable Platforms: Suitable for Volvo TD121, Mack 485-GB-3191, Renault series engines
Fleetguard LF3716 Oil Filter
Fleetguard Filters | LF3716 Oil Filter
Applicable Series: Daewoo DH220/DH300, Doosan DL08/DL06 Heavy Duty Diesel Engine
Part Name: LF3716 Oil Filter
Part Number: Original Equipment OE Number: 65055105017/2474-9052/2474-9052A/65055105020
Applicable Platforms: Suitable for Daewoo DH220/DH300 excavator, Doosan DL08/DL06 series engines
Fleetguard LF3764 Oil Filter
Fleetguard Filters | LF3764 Oil Filter
Applicable Series: Isuzu 4JB1, 4BD1, 4HK1, 6HK1, QD32 Heavy Duty Diesel Engine
Part Name: LF3764 Oil Filter
Part Number: Original Equipment OE Number: 8-97049708-1/4650205/1012160TA/8-94217272-1/8-4432663-1
Applicable Platforms: Suitable for Isuzu 4JB1 (90-120HP), 4BD1 (120-160HP), 4HK1 (180-240HP), 6HK1 (260-350HP), QD32 (130-150HP) series engines
Fleetguard LF3970 Oil Filter
Fleetguard Filters | LF3970 Oil Filter
Applicable Series: Cummins ISB 5.9L/6.7L, QSB 6.7L, B-Series Heavy Duty Diesel Engine
Part Name: LF3970 Oil Filter
Part Number: Original Equipment OE Number: 3937736/5404947/3937736/5282889
Applicable Platforms: Suitable for Cummins ISB 5.9L (215-325HP), ISB 6.7L (300-385HP), QSB 6.7L (190-300HP) series engines
