Fleetguard LF3321 Oil Filter

Fleetguard LF3321 is a high – performance full – flow spin – on oil filter, mainly designed for Cummins N14/K19/M11, Volvo heavy – duty diesel engines, and Case IH agricultural machinery engines, and is widely used in heavy trucks, large – scale construction machinery (such as large loaders, excavators), agricultural equipment (such as tractors, harvesters), and industrial generator sets.

The filter adopts high – quality cellulose composite filter media, which can achieve 98% filtration efficiency at 25 microns, effectively capturing metal shavings, carbon deposits, and colloidal impurities in the lubrication system, protecting engine bearings, camshafts, and turbochargers from premature wear, and ensuring stable operation under long – term heavy – load working conditions.

Key specifications: 108mm outer diameter, 260.5mm height, 1 1/8-16 UN-2B thread, 100.2×92.2mm seal ring. It supports tool – free quick installation and can maintain stable performance in the temperature range of -30°C to 120°C. It is an ideal maintenance accessory for heavy – duty vehicle fleets, agricultural machinery, and industrial equipment.

Advantages of  LF3321 Oil Filter

  • Broad Compatibility: Suitable for multiple mainstream heavy – duty and agricultural diesel engines, perfectly matching the original oil circuit system, with zero compatibility risk, providing reliable protection for various heavy – load equipment.

  • High – Precision Filtration: 25 – micron precision captures 98% of contaminants, reduces engine wear by 25%, and extends the oil change interval by 20%, ideal for long – term continuous operation scenarios.

  • Durable Structure: The reinforced steel shell can withstand 8bar oil pressure and 3G vibration load, and can adapt to harsh working conditions such as mining, construction sites, and farmland.

  • Convenient Maintenance: Tool – free installation enables replacement to be completed within 2 minutes, minimizing equipment downtime for fleet and agricultural machinery teams.

  • Cost – Effective Solution: It has OEM – level quality and a price 20% lower than that of original parts, which can significantly reduce the maintenance cost of heavy – duty vehicle and agricultural machinery fleets.

Technical Specifications

Part Number: LF3321
Filter Type: Oil Filter
Dimensions: OD≈φ108mm, Total Height≈260mm
Connection Specs Thread Specification: 1 1/8-16 UN-2B
Filtration Precision: 25μm(TWA Standard)
Filtration Efficiency: ≥98% (25μm, TWA Standard)
Applicable Models/Platforms: Volvo 466634; Ingersoll-Rand 85401909
Operating Conditions: Temp: -40~120℃; Pressure: ≤12bar; Flow rate: ≥38L/h
Lead Time: 15 – 30 Working Days
Payment Terms: T/T ,L/C

coming soon

coming soon

coming soon

Engine Model

Dimensions

Connection Specs

Filtration Precision

Filtration Efficiency

LF3321 OD≈φ108mm, Total Height≈260mm Thread Specification: 1 1/8-16 UN-2B 25μm ≥98% (ISO 4548 Standard)
LF3970 OD≈φ93mm, Total Height≈176mm Thread Specification: 1 1/8-16 UN-2B 30μm ≥98% (ISO 4548 Standard)
LF3764 OD≈φ93mm, Total Height≈100mm Thread Specification: M20×1.5-6H 30μm ≥98% (ISO 4548 Standard)
LF3716 OD≈φ116mm, Total Height≈249mm Thread Specification: 1 1/2-12 UNS-2B 30μm ≥95% (ISO 4548 Standard)
LF3806 OD≈φ93mm, Total Height≈176mm Thread Specification: 1-16 UN-2B 30μm ≥98% (ISO 4548 Standard)
LF691A OD≈φ135mm, Total Height≈309mm Thread Specification: 1 1/2-16 UNS-2B 30μm ≥95% (ISO 4548 Standard)
LF9050 OD≈φ119mm, Total Height≈297mm Thread Specification: M90×2-7H INT 30μm ≥98% (ISO 4548 Standard)
LF9070 OD≈φ118mm, Total Height≈352mm Thread Specification: M95×2.5-7H INT 30μm ≥98% (ISO 4548 Standard)
LF9009 OD≈φ118mm, Total Height≈301mm Thread Specification: 2 1/4-12 UNS-2B 30μm ≥98% (ISO 4548 Standard)
LF3349 OD≈φ93mm, Total Height≈176mm Thread Specification: 1-16 UN-2B 30μm ≥95% (ISO 4548 Standard)
L131-030-AM 00MX OD≈φ83mm, Total Height≈155mm Thread Specification: M20×1.5-6H INT 20μm ≥98% (ISO 4548 Standard)
——END——

General Infomation of DCEC C220-10A Automotive Engine

Engine Model C220-10A Advertised Power 220 HP @ 2400 RPM
Peak Torque 780 N.m @ 1500 RPM Curve&Datasheet FR 91484
Fuel System Bosch P7100 Pump No. Of Cylinders 6
Aspiration Turbocharged & Air Intercooler Displacement 8.3 L
Bore * Stroke 114 mm * 135 mm CPL Code Revision 8418
Dry Weight  617 kg Wet Weight  636 kg
Compression Ratio 17.3 : 1

Installation Data of DCEC C220-10A Automotive Engine

Center of Gravity. Distance From Front Face of Block 427 mm
Center of Gravity. Distance Above Crank Centerline(Above Crankshaft) 163 mm
Maximum Bending Moment At Rear Face of Block 1356 N.m
Maximum Crankshaft Thrust Bearing load limit- Intermittent load 3558 N
Maximum Crankshaft Thrust Bearing load limit-Continuous load 2670 N
Instantaneous Inertia At Rotating: (Without Flywheel)  N/A
Emissions Certification GB17691/GB14761
Idle Speed 800 RPM
Maximum Non-Load Speed 2720 RPM
Over Speed Performance (Within 15 Seconds) 3500 RPM
The Clutch Torque @ 800Rpm 495 N.m
Maximum Altitude At Which Continuous operation Is Allowed 3000 m
Supercharger outlet Exhaust Pressure limit Value  450 kPa
Maximum Power of Exhaust Brake 114 kW
——END——

Engine Performance Data Rated power of DCEC C220-10A Automotive Drive Engine

Rated Power Torque Peak Rated Power Torque Peak
Engine Speed 2400 RPM 1500 RPM Exhaust Temperature 625 ℃ 602 ℃
Oil Pressure 345 kPa 282 kPa Fuel Consumption 43 L/hr 26.9 L/hr
The Air Flow 18.9 m³/min 9.1 m³/min Coolant Flow N/A N/A
The Flow Rate of Pressurized Air N/A N/A Heat Loss Coolant 77 kW 60 kW
Pressurized Air Pressure N/A N/A Heat Loss Air 46 kW 14 kW
The Exhaust Flow 45 m³/min 21.3 m³/min Mechanical Loss of Power N/A N/A


System Technical Data of DCEC C220-10A Automotive Drive Engine

Air Intake System Maximum Temperature Rise Between Ambient Air and Engine Air Inlet 15 ℃
Maximum Intake Restriction with Dry Type Air Cleaner,with Clean Filter-Medium Duty 2.9 (300) kPa (mmH2O)
Maximum Intake Restriction with Dry Type Air Cleaner,with Clean Filter-Heavy Duty 3.7 (380) kPa (mmH2O)
Maximum Intake Restriction with Dirty Filter 6.2 (635) kPa (mmH2O)
Turbocharged & Intercooled Maximum Intake Manifold Temperature-Second Level 55 ℃
Maximum Intake Manifold Temperature-Three-Level 50 ℃
Intercooler Cooling Temperature-Second Level 25 ℃
Intercooler Cooling Temperature-Three-Level 20 ℃
Maximum Allowable Pressure Difference Before and After Intercooling-Three-Level 16.7 (125) kPa(mmHg)
Minimum Inlet Pipe Diameter Allowed-Three-Level 75 mm
Exhaust System Maximum Back Pressure Imposed by Complete Exhaust System 10.0 (75) kPa (mmHg)
Exhaust Pipe Size Normally Accepable 75 mm
Maximum Static Bend Allowed for Turbocharger Exhaust Flange N/A
Lubrication System Low oil Level Inclination Angle-Front Up 45 °
Low oil Level Inclination Angle-Back Up 45 °
Low oil Level Inclination Angle-Fuel Pump Side Up 45 °
Low oil Level Inclination Angle-Exhaust Side Up 45 °
Oil Sump Capacity-Upper Limit 14.2 L
Oil Sump Capacity-Lower Limit 12.4 L
Capacity of The Whole System 16.4 L
Cooling System Coolant Capacity – Engine only 9 L
Standard Thermostat (Modulating) Range 83 – 95 ℃
Minimum Fill Rate ( Without Low Level Alarm) 19 L/min
Minimum Coolant Expansion Space – % of System Capacity 6 %
Water Tank Capacity Without Water Expansion 6 L
Maximum Coolant Pressure (Without Pressure Cap, Thermostat Closed) 276 kPa
Maximum Degassing Time 25 mins
Maximum Coolant Flow to Accessories 41 L/min
Maximum Coolant Temperature Engine out 100 ℃
Minimum Allows Pressure of Pressure Cap 50 kPa
Minimum Recommended Coolant Temperature 70 ℃
Common Operating Temperature Range of Fans with Fan Clutch 93 ℃
Maximum Coolent Temperature For Engine Protection Control 100 ℃
The Limit Environmental Temperature at Rated Speed Second Level 45 ℃;Three-Level 42 ℃
The Limit Environmental Temperature at Peak Torque Second Level 40 ℃;Three-Level 37 ℃
24V Electrical System Maximum Allowable Resistance of Cranking Circuit 0.002 Ω
The Cold Start Current When Engine and The Clutch Separate 12 V 500 24 V 250
Cold Starting System Maximum Unaided Cold Start Temperature 120 RPM -10 ℃
Maximum Aided Cold Start Temperature 110 RPM -35 ℃
Fuel System Maximum Fuel Return Resistance 520 (mmHg)
Maximum Inlet Resistance of oil Pump with Clean Filter 150 (mmHg)
——END——

Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
