Fleetguard FS19594 Oil-Water Separator

Fleetguard FS19594 is a high-performance spin-on Oil-Water Separator engineered for diesel fuel systems, specialized in medium-duty commercial vehicles and industrial machinery powered by Cummins engines. Adopting Strata Pore filter media, it efficiently removes 20μm solid particulates and free/emulsified water from fuel, delivering clean fuel to core components and effectively preventing corrosion and wear of fuel injection systems.

This separator features a compact and optimized design, with an outer diameter of 76.71mm and an overall height of 141.71mm, paired with 3/4-16 UNF-2B threaded port. It perfectly fits the limited mounting space of medium-duty trucks and engineering machinery, enabling tool-free quick installation and replacement, and is fully compatible with Cummins C6003117480 and other mainstream engine models.

Compliant with SAE J1985 industry standards, FS19594 undergoes strict factory performance testing. It has no WIF sensor provision and maintains stable filtration performance under various complex working conditions, serving as a reliable OEM filtration part for medium-duty diesel equipment in transportation and industrial fields.

Advantages of  FS19594 Oil-Water Separator

  • Efficient filtration & water separation: It achieves 96% filtration efficiency for 20μm particulates and 90% separation efficiency for both free and emulsified water in fuel, thoroughly eliminating fuel contamination and reducing the failure risk of engine fuel systems.

  • Premium filter media performance: The proprietary Strata Pore media ensures high dirt-holding capacity and stable fuel flow rate, maintaining consistent filtration efficiency throughout the service life and lowering equipment maintenance frequency.

  • Excellent structural compatibility: With compact dimensional design and standard 3/4-16 UNF-2B threaded interface, it perfectly matches medium-duty Cummins engines and mainstream medium-duty commercial vehicles, realizing direct and quick replacement.

  • Reliable durability & adaptability: Constructed with high-strength metal canister and premium sealing gaskets, it resists vibration and pressure impact in harsh working environments, with no leakage risk and stable performance for long-term operation.

Technical Specifications

Part Number: FS19594
Filter Type: Oil-Water Separator
Dimensions: Outer Diameter≈76.71mm, Overall Height≈141.71mm
Connection Specs: Thread Specification: 3/4-16 UNF-2B
Filtration Precision: 20μm
Filtration Efficiency: ≥96% (ISO 4548 Standard)
Applicable Models/Platforms: Medium-Duty Commercial Vehicles, Cummins Engines, Industrial Machinery
Operating Conditions: Temperature: -40℃~120℃; Pressure: 0.1~1.2MPa
Lead Time: 15 – 30 Working Days
Payment Terms: T/T ,L/C

Filter Model

Dimensions

Connection Specs

Filtration Precision

Filtration Efficiency

FS19594 Outer Diameter≈76.71mm, Overall Height≈141.71mm Thread Specification: 3/4-16 UNF-2B 20μm ≥96% (ISO 4548 Standard)
FS19594 00MX Outer Diameter≈77mm, Overall Height≈144.5mm Thread Specification: 3/4″-16 Threaded Interface 20μm 96%(ISO 4548 Standard)
FS19544 00MX Outer Diameter≈77.6mm, Overall Height≈149mm Thread Specification: M16×1.5 Threaded Interface 25μm 98%(ISO 4548 Standard)
FS19816 00MX Outer Diameter≈120.5mm, Overall Height≈204.5mm Thread Specification:1″-14 UNS-2B Threaded Interface 25μm 98.7%(ISO 4548 Standard)
F189-020-AM Outer Diameter≈93.22mm, Overall Height≈249.07mm Thread Specification: 1-14 UNS – 2B Thread 5μm ≥99% (ISO 4548 Standard)
FS19587 00MX Outer Diameter≈77mm, Overall Height≈155mm Thread Specification: M20×1.5 5μm ≥99.6% (ISO 4548 Standard)
FS1280 Outer Diameter≈93.73mm, Overall Height≈164.85mm Thread Specification: 13/16″-18 UNS-2B 20μm ≥96%(ISO 4548 Standard)
FS1000 Outer Diameter≈93.22mm, Overall Height≈ 249.07mm Thread Specification: 1-14 UNS-2B 10μm ≥98.7%(ISO 4548 Standard)
FS19732 00MX Outer Diameter≈94.5mm, Overall Height≈201mm Thread Specification: 1″-14 UNS-2B Threaded Interface 25μm 98.7% (ISO 4548 Standard)
FS19898 00MX Outer Diameter≈109mm, Overall Height≈299mm Thread Specification: 1″-14 UNF Threaded Interface 25μm 98.7% (ISO 4548 Standard)
FS19686 00MX Outer Diameter≈93mm, Overall Height≈208mm Thread Specification: 1″-14 UNS-2B Threaded Interface 25μm 98.7%(ISO 4548 Standard)
FS19789 00MX Outer Diameter≈110mm, Overall Height≈265mm Thread Specification: 1″-14 UNS-2B Threaded Interface 25μm 98.7% (ISO 4548 Standard)
F192-001 Outer Diameter≈92mm, Overall Height≈165mm Thread Specification: M18×1.5 5μm ≥99.6%(ISO 4548 Standard)
FS1212 Outer Diameter≈93.22mm, Overall Height≈201.17mm Thread Specification: 1-14 UNS-2B 20μm ≥96%(ISO 4548 Standard)
FS1242 Outer Diameter≈93.04mm, Overall Height≈174.9mm Thread Specification: 1-14 UNS-2B 20μm ≥96% (ISO 4548 Standard)
FS19925-FGC Outer Diameter≈81.2mm, Overall Height≈113mm Thread Specification: M18×1.5 25μm 98.7% (ISO 4548 Standard)
------END------

General Infomation of DCEC C220-10A Automotive Engine

Engine Model C220-10A Advertised Power 220 HP @ 2400 RPM
Peak Torque 780 N.m @ 1500 RPM Curve&Datasheet FR 91484
Fuel System Bosch P7100 Pump No. Of Cylinders 6
Aspiration Turbocharged & Air Intercooler Displacement 8.3 L
Bore * Stroke 114 mm * 135 mm CPL Code Revision 8418
Dry Weight  617 kg Wet Weight  636 kg
Compression Ratio 17.3 : 1

Installation Data of DCEC C220-10A Automotive Engine

Center of Gravity. Distance From Front Face of Block 427 mm
Center of Gravity. Distance Above Crank Centerline(Above Crankshaft) 163 mm
Maximum Bending Moment At Rear Face of Block 1356 N.m
Maximum Crankshaft Thrust Bearing load limit- Intermittent load 3558 N
Maximum Crankshaft Thrust Bearing load limit-Continuous load 2670 N
Instantaneous Inertia At Rotating: (Without Flywheel)  N/A
Emissions Certification GB17691/GB14761
Idle Speed 800 RPM
Maximum Non-Load Speed 2720 RPM
Over Speed Performance (Within 15 Seconds) 3500 RPM
The Clutch Torque @ 800Rpm 495 N.m
Maximum Altitude At Which Continuous operation Is Allowed 3000 m
Supercharger outlet Exhaust Pressure limit Value  450 kPa
Maximum Power of Exhaust Brake 114 kW
------END------

Engine Performance Data Rated power of DCEC C220-10A Automotive Drive Engine

Rated Power Torque Peak Rated Power Torque Peak
Engine Speed 2400 RPM 1500 RPM Exhaust Temperature 625 ℃ 602 ℃
Oil Pressure 345 kPa 282 kPa Fuel Consumption 43 L/hr 26.9 L/hr
The Air Flow 18.9 m³/min 9.1 m³/min Coolant Flow N/A N/A
The Flow Rate of Pressurized Air N/A N/A Heat Loss Coolant 77 kW 60 kW
Pressurized Air Pressure N/A N/A Heat Loss Air 46 kW 14 kW
The Exhaust Flow 45 m³/min 21.3 m³/min Mechanical Loss of Power N/A N/A


System Technical Data of DCEC C220-10A Automotive Drive Engine

Air Intake System Maximum Temperature Rise Between Ambient Air and Engine Air Inlet 15 ℃
Maximum Intake Restriction with Dry Type Air Cleaner,with Clean Filter-Medium Duty 2.9 (300) kPa (mmH2O)
Maximum Intake Restriction with Dry Type Air Cleaner,with Clean Filter-Heavy Duty 3.7 (380) kPa (mmH2O)
Maximum Intake Restriction with Dirty Filter 6.2 (635) kPa (mmH2O)
Turbocharged & Intercooled Maximum Intake Manifold Temperature-Second Level 55 ℃
Maximum Intake Manifold Temperature-Three-Level 50 ℃
Intercooler Cooling Temperature-Second Level 25 ℃
Intercooler Cooling Temperature-Three-Level 20 ℃
Maximum Allowable Pressure Difference Before and After Intercooling-Three-Level 16.7 (125) kPa(mmHg)
Minimum Inlet Pipe Diameter Allowed-Three-Level 75 mm
Exhaust System Maximum Back Pressure Imposed by Complete Exhaust System 10.0 (75) kPa (mmHg)
Exhaust Pipe Size Normally Accepable 75 mm
Maximum Static Bend Allowed for Turbocharger Exhaust Flange N/A
Lubrication System Low oil Level Inclination Angle-Front Up 45 °
Low oil Level Inclination Angle-Back Up 45 °
Low oil Level Inclination Angle-Fuel Pump Side Up 45 °
Low oil Level Inclination Angle-Exhaust Side Up 45 °
Oil Sump Capacity-Upper Limit 14.2 L
Oil Sump Capacity-Lower Limit 12.4 L
Capacity of The Whole System 16.4 L
Cooling System Coolant Capacity - Engine only 9 L
Standard Thermostat (Modulating) Range 83 - 95 ℃
Minimum Fill Rate ( Without Low Level Alarm) 19 L/min
Minimum Coolant Expansion Space - % of System Capacity 6 %
Water Tank Capacity Without Water Expansion 6 L
Maximum Coolant Pressure (Without Pressure Cap, Thermostat Closed) 276 kPa
Maximum Degassing Time 25 mins
Maximum Coolant Flow to Accessories 41 L/min
Maximum Coolant Temperature Engine out 100 ℃
Minimum Allows Pressure of Pressure Cap 50 kPa
Minimum Recommended Coolant Temperature 70 ℃
Common Operating Temperature Range of Fans with Fan Clutch 93 ℃
Maximum Coolent Temperature For Engine Protection Control 100 ℃
The Limit Environmental Temperature at Rated Speed Second Level 45 ℃;Three-Level 42 ℃
The Limit Environmental Temperature at Peak Torque Second Level 40 ℃;Three-Level 37 ℃
24V Electrical System Maximum Allowable Resistance of Cranking Circuit 0.002 Ω
The Cold Start Current When Engine and The Clutch Separate 12 V 500 24 V 250
Cold Starting System Maximum Unaided Cold Start Temperature 120 RPM -10 ℃
Maximum Aided Cold Start Temperature 110 RPM -35 ℃
Fuel System Maximum Fuel Return Resistance 520 (mmHg)
Maximum Inlet Resistance of oil Pump with Clean Filter 150 (mmHg)
------END------

Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
