PartMac Other Filters
Other Filters refer to a variety of filtration systems that serve specific purposes beyond the engine’s core filtration needs.
These may include hydraulic filters that clean the fluid used in hydraulic systems, transmission filters that maintain the cleanliness of transmission fluid, and cabin air filters that ensure the air inside the vehicle is free from pollutants.
These filters are designed to protect various systems and components from contamination and wear, contributing to the overall reliability and longevity of the vehicle.
Advantages of Other Filters
Other filters, such as hydraulic and transmission filters, offer the advantage of protecting specialized systems within a vehicle.
They maintain the purity of the fluids, which is vital for the smooth operation of hydraulic systems and transmission.
These filters help prevent system failures and extend the life of the components they serve, leading to better vehicle reliability and reduced maintenance costs.
| 120-150 HP | ||||||||
| 188-254 HP | ||||||||
| 300-315 HP | ||||||||
| 308 HP | ||||||||
| 47-65 kW | ||||||||
| 80-132 kW | ||||||||
| 115-175 kW | ||||||||
| 200-215 kW | ||||||||
Engine Model Power/HP & kW | 0 | 50 | 100 | 150 | 200 | 250 | 300 | 350 |
| Emission Srandard:Euro ⅠEuro ⅡEuro ⅢEuro ⅣEuro ⅤEuro ⅥEuro Ⅶ | ||||||||
| DCEC Marine Main Engine Catalogue | ||||||||
| 6BT5.9-M120 | 120 HP @ 2200 RPM | 6BTA5.9-M150 | 150 HP @ 2200 RPM | |||||||
6CTA8.3 1494 mm * 796 mm * 1228mm Euro Stage II | 6CTA8.3-M188 | 188 HP @ 2328 RPM | 6CTA8.3-M205 | 205 HP @ 2328 RPM | 6CTA8.3-M220 | 220 HP @ 1800 RPM | 6CTAA8.3-M260 | 254 HP @ 2134 RPM | ||||
6LTAA8.9 1494 mm * 796 mm * 1228 mm Euro Stage II | 6LTAA8.9-M300 | 300 BHP @ 1800 RPM | 6LTAA8.9-M315 | 315 BHP @ 2134 RPM | ||||||
QSL8.9 1494 mm * 796 mm * 1228 mm Euro Stage III | QSL8.9-M313 | 308 HP @ 2200 RPM | |||||||
| ——END—— | ||||||||
| DCEC Marine Auxiliary Engine Catalogue | ||||||||
4BT3.9 1100 mm * 800 mm * 1200 mm Euro ll | 4BTA3.9-GM47 | 47 kW @ 1500 RPM | 4BTA3.9-GM65 | 65 kW @ 1800 RPM | ||||||
6BT5.9 1182 mm * 761 mm * 1127 mm Euro ll | 6BT5.9-GM80 | 80 kW @ 1500 RPM | 6BT5.9-GM83 | 83 kW @ 1500 RPM | 6BT5.9-GM100 | 100 kW @ 1800 RPM | 6BTA5.9-GM100 | 100 kW @ 1500 RPM | ||||
| 6BTA5.9-GM120 | 120 kW @ 1800 RPM | 6BTAA5.9-GM115 | 115 kW @ 1500 RPM | |||||||
6CTA8.3 1494 mm * 796 mm * 1228 mm Euro ll | 6CT8.3-GM115 | 115 kW @ 1500 RPM | 6CT8.3-GM129 | 129 kW @ 1800 RPM | 6CTA8.3-GM155 | 155 kW @ 1500 RPM | 6CTA8.3-GM175 | 175 kW @ 1800 RPM | ||||
6LTAA8.9 1400 mm * 900 mm * 1100 mm Euro ll | 6LTAA8.9-GM200 |200 kW @ 1500 RPM | 6LTAA8.9-GM215 | 215 kW @ 1800 RPM | ||||||
| ——END—— | ||||||||
Find Marine Engines by Series
This is the list of all series of DCEC marine engines.
Click here to find marine engines by type (Fuel System & Power Range).
